Sharp 10W 0-10V Dimmale 80mm Cutout COB LED Downlight

US$ 14 - 21 MOQ: 1 Piece

Key Specifications

LED Light Source:

Sharp

Warranty(Years):

Input Voltage(V):

200-240V AC

Shenzhen Singten Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Sharp

Warranty(Years) 3

Input Voltage(V) 200-240V AC

Lamp Power(W) 10

Lamp Luminous Flux(lm) 667lm to 691lm

Lamp Luminous Efficiency(lm/w) 69

Color Temperature(CCT) Other, 2700/3000/4000/5000K

Working Temperature(℃) -20, +50

Working Lifetime(Hour) 35000

Lamp Body Material Aluminum

IP Rating Other, IP20

Certification CE, EMC, GS, LVD, SAA

Model Number KWT-RD10FSPFWL

Place of Origin Guangdong, China

Brand Name KWT

Specifications

Sharp 10W 0-10V Dimmale 80mm Cutout COB LED Downlight
1.10/13/15/25W Available
2.TUV GS SAA CB CE RoHS
3.3 Years Warranty

Sharp 10W 0-10V Dimmale 80mm Cutout COB LED Downlight

Product Features:

1. Environment friendly, no UV or IR light radiation.

2. No mercury or other inorganic.

3. Energy saving, low power consumption,high efficiency.

4. Color: Warm white/Natural white/Cool white.

5 .Original Sharp Citizen LED Source ,High Quality ,Lower Lumens depreciation

6. Maintenance free,Simple installation, it is an excellent replacement of conventional light

Product Description

Specification
Product Name	Sharp 10W 0-10V Dimmale 80mm Cutout COB LED Downlight
Model No	KWT-RD10FSPFWL
Power	23W
LED Source	Sharp
Voltage&Current&Frequency	240mA;50/60Hz
Beam Angle	65degree
CCT Range	WW--2700K 3000K ,NW--4000K ,CW--5000K
Luminious Flux	667lm to 691lm
Color Index	≥82
Power Factor	≥0.92
Dimming Type	Triac / 0-10V / C-Bus
Dimension	91mm D x 85mm H
Cut out size	80mm
Finish Color	White/Silver
Install Type	Recessed
Material	Aluminum + PC cover
IP Grade	IP20
Life Span	≥35,000 hours
Work Temp	-20-+50degree
Certification	TUV GS SAA CE ROHS CB
Packing	Weight:18.5kgs Quantity:24pcs Size(LxWxH):500 x 305 x 462mm
Lumens Decline	30% after 50,000hrs
