| Equipment Specifications -shredder | |||||||||||||||
| TSD2471(182) | TSD1663(137) | TSD1651 | TSD1347(86) | TSD1340 | TSD1332 | TSD832 | |||||||||
| Motor Specifications | Electric | Electric | Electric | Electric | Electric | Electric | Electric | ||||||||
| Number of Motors | 2 | 2 | 2 | 2 | 2 | 2 | 2 | ||||||||
| HP | 55KWX2 | 45KWX2 | 37KWX2 | 22KWX2 | 22KWX2 | 15KWX2 | 7.5KWX2 | ||||||||
| Voltage | as per customer request | ||||||||||||||
| Cutting Chamber | Split Chamber | Split Chamber | Split Chamber | intact Chamber | intact Chamber | intact Chamber | intact Chamber | ||||||||
| Large Blade Thickness | 75mm | 75mm | 75mm | 40mm | 40mm | 40mm | 40mm | ||||||||
| Small Blade Thickness | 40mm | 40mm | 40mm | / | / | / | / | ||||||||
| Blade Diameter | 754mm | 542mm | 542mm | 450mm | 450mm | 450mm | 284mm | ||||||||
| Cutting Chamber L*W | 1804X1410 | 1604X858 | 1304X858 | 1204X686 | 1004x686 | 804x686 | 804x460 | ||||||||
| Equipment Dimensions | 5876x2310x3493 |
5464x2624 x3040 |
4280x2206 x2492 |
4092x1416 x2163 |
3892x1416 x2163 |
3327x1030 x2075 |
2796x1256 x2311 |
||||||||
| Equipment Weight | 22400kg | 13700kg | 12500kg | 6300kg | 5800kg | 4700kg | 2000kg | ||||||||
| Hopper Opening | 3711x2438x1046 |
2835x1628 x770 |
2335x1628 x770 |
1521x1416 x695 |
1321x1416 x695 |
1120x1257 x800 |
1120x1256 x800 |
||||||||
| Capacity | 15-20t/h | 10-15t/h | 5-10t/h | 3-5t/h | 2-3t/h | 1-2t/h | 800-1000kg/h | ||||||||
| Product Size Range | 40mm-75mm | 40mm-75mm | 40mm-75mm | 40mm chips | 40mm chips | 40mm chips | 40mm chips | ||||||||
Rubber shredding machine
Advantages of the System
Unique Stop/Auto Reversal Feature – Protects against overfeeding and damage by non-processable items.
Premier Full Turn Key Systems – Plant is manufactured, shipped, installed and ready to start recycling.
Warranty – one of the best warrantees in the industry.
Dura-Shred’s two shaft shredders are designed with an aggressive low RPM, high torque shredding technology.
Granulator
The Granulators are designed to grind the rubber mulch from the Grater into small granules as fine as 10 mesh.
The granules are screened and re-circulated until the desired size is reached.
Due to the design of the our granulator and precise alignment of the blades, this Granulator produces a very uniform cut, high quality granule.
During the granulation process, 99% of the fiber is removed, leaving a contaminant free crumb rubber granulate ready to be further processed or sold.
Miller
Dura-shred's miller is designed for rubber material where a powdered products is required.
Granules of size 1-8mm is fed via feeder to the rotating high speed serrated disk to produce a powder product in the required 30-120mesh range and where the final size is determined by adjustable centrifugal screen.
About Dura Shred
Since 2001
Designing and manufacturing equipment for the recycling industry
a variety of applications such as TDF (Tire Derived Fuel), rubber mulch, and crumb rubber.
manufactured and installed recycling systems in countries all over the world, including the US, Canada, Mexico, Poland,South America, South Africa, Iraq, and Kazakhstan etc.
Our production plant is located in Wuxi, China with headquarters in Shanghai, China.
Dura-Shred’s mission is to provide our customers with cost effective turnkey recycling equipment.
We can provide customized shredding system for our global clients.
Comprehensive service: System Design, Manufacturing, Import/Export, and Logistic service.
Dura-shred is committed to provide our customers with proven western designed equipment with first class technical support and service.
Packaging Details: as per customer request or our netrual package - a layer of plastic wraps
to protect machine from dust,moisture and corrosion. Wooden case as the outside package.
Delivery Detail: 30 days after deposit.
A. 1 year warranty
B. We will send 2 or 3 engineers to help install the machines.
C. OEM & ODM are available
D. Turn-Key service
E. Rubber samples could be supplied for free
F. Regular return visit
1. How to choose the suitable machine?
Please answer first:
a: What material do you want to shred?
b: What is the usage of the crushing material?
c: How many tons per hour do you demand?
After that, the suitable machine could been introduced to you.
2. What about the shipping and package?
We arrange shipment according to your requirements. It is included in our TURNKEY service.
3. Can I visit your company or factory?
Ofcourse you can.
Our headquarter is in Shanghai city
Our production plant is in Wuxi city, Jiangsu province.
And when you fly to China, we could pick you up and afford your local transportation charges.
4. What's the relationships between tqwinner and dura-shred?
They are 2 brands belonging to the same group. Dura-Shred is registered in Wuxi; Qqwinner in Shanghai. Our headoffice and marketing team are located in Shanghai.
Factory Size(ters): Above 100,000 square meters
Factory Location:
No.24,Cangsifang,Dengxiang Village, Qianzhou Town,Huishan District,Wuxi City,Jiangsu Provice,China
Number of R&D Staff: 5 - 10 People
Number of QC Staff: 5 - 10 People
Contract Manufacturing: OEM Service Offered Design Service Offered
Please feel free to contact Tina by MB: 0086 186 166 49733 Skype: tina.deer.zhang
