Specifications
German technology,high quality AGM materials manufactured,competitive price with 1 years quality warranty.long service lifeProduct Performance:
-Long design life(25ºC): 5-8 years
-Low self-discharge rate:<=3%/month
-Good high rate discharge performance
-High sealed reaction efficiency: >=99%
-Wide operation temperature range: -20ºC~60ºC
Applications:
- Fire protection and security uninterruptible power supply
- Electronic appliance and other backup power supply
- Telephone and telecommunication equipment
- Electric toysPower toolsPortable Lights
- Uninterruptible power supplies (UPS)
- Emergency lighting or small lamp fitting
- Electric bike/motorcycle
- Remote Switching
- Solar power system
- Solar light
Technical Specification :
Nominal Voltage |
12V |
||
Nominal Capacity (20 hour rate) |
24Ah |
||
|
Capacity 25oC (77°F) |
20 hour rate (1.33A) |
20Ah |
|
5 hour rate (4.4A) |
18Ah |
||
1 hour rate (16.0A) |
16.0Ah |
||
Internal Resistance |
Full Charged Battery 25oC |
≤14mΩ |
|
|
Capacity affected by Temperature (20 hour ) |
40oC (104°F) |
102% |
|
|
25oC (77°F) |
100% |
||
|
0oC (32°F) |
85% |
||
|
-15oC (5°F) |
65% |
||
|
Self-Discharge 25oC (77°F) Capacity |
after 3 month storage |
90% |
|
after 6 month storage |
80% |
||
after 12 month storage |
62% |
||
|
Charge (Constant Voltage) 25oC (77°F) |
Float |
Initial Charging Current Less than 6.0A Voltage 13.6-13.8V |
|
Cycle |
Initial Charging Current Less than 6.0A Voltage 14.4-14.9V |
||
Battery Dimensions |
Length |
166mm |
Width |
126mm |
|
Height |
174mm |
|
Total Height |
178mm |
|
Box Dimensions |
Length |
273mm |
Width |
178mm |
|
Height |
220mm |
|
Quantity Per Box |
2 PC per box |
|
Net weight Per Cell |
8.1 kg±100g |
|
Net weight Per Box |
16.2kg |
|
Gross Weight |
16.6kg |
|
|
|
|
Limited Guarantee and Service Commitment
Product Quality
1.We are liable to remedize or replace the batteries for any defects in materials andworkmanship if they come from our factory and stay within the legitimatewarranty.
2.We will response to your failure-report within 24 hours with a solution ,and willdispatch technician to field if it is necessary.
3.We offerlife-long service to every single of our batteries(free of charge if covered bywarranty),and technical instruction included.
Follow-up Service
1.Our technicans are available for your on-site installation guidance andengineering.
2.We are ready to answer your questions about our products(remote or on-site)untilproblems are solved and deliver
technical trainging upon your specific demand.
