Help CenterLDPE DUCT
Related Products
Specifications
1.Use in protcting optical cable or telecom cable.2.Most advanced cable jecket material.
4.Certificate:9001:2000
Contact Information
Sales Manager: Danny
Mobile Phone: 0086 15075828982
Tel: +86 3187091666
Fax: +86 3187952199
Website: www. /www. hsbaoli. cn
Companies: CHINA BAOLI GROUP
Address: No.1888 Heping West Road, Hengshui City, Hebei Province, China.
Product Description
LDPE DUCT is a new-type composite pipe with silicone compound solid lubricant in its
inner wall, referred to as silicon tube. It is extruded composited by three plastic extruders and the main
raw material is high-density polyethylene.
The core layer is solid silicone lubricant, which has the lowest coefficient of friction. The silicon core of inner wall
is solid and to be a permanent lubricants. And the friction characteristics of silicon core will remain unchanged so that
the cable can be extracted repeatedly in pipe, and It has the same physical and mechanical properties as the HDPE, so
it will not peel and with the same life as LDPE.
The pipe is convenient in construction and greatly reduce the project cost. Neither need the jacket pipe nor subduct, the cables can through directly in silicon core pipe. Each (cycle) silicon core pipe can be made of any length, since the length is generally 2000 meters, then the men- well can be set every 1, 000m. Using the air blowing to wear cables, so it
only need 15 minutes each 1, 000 meters. It is widely used in optical cable communication network system.
The silicon core layer will not react with water and can be washed with water after the accident occurred. And radius of curvature for silicon core pipe is small (ten times than its diameter. ), if meet the bend and the gap when laying, it can be determined with the environment without doing any treatment.
Features:
1. Tensile resistance, compression resistance, impact resistance, and need no subduct;
2. A low friction smooth surface make it easy to draw or blow the cable repeatedly;
3. Good tightness, waterproof, can avoid the damage by rodent animals;
4. Weathering resistance and can be used between -30° C to 80° C;
5. Aging resistance, long service life and can work for over 50 years underground.
Application scope
Applies to the piping system of outside communication cable and optical cable, or construction for public information network, public transmission system, cable television network and freeway communication.
Product specification and technical parameter
Dimension (unit: mm):
specification |
OD |
min ID |
thickness |
length |
elasticity |
|
before coiling |
after coiling |
|||||
32/26 |
32 |
26 |
2.5 |
1000 |
≤2 |
≤3 |
34/28 |
34 |
28 |
3.0 |
1000 |
≤2 |
≤3 |
40/33 |
40 |
33 |
3.5 |
1000 |
≤2.5 |
≤3.5 |
46/38 |
46 |
38 |
4.0 |
1000 |
≤3 |
≤5 |
50/41 |
50 |
41 |
4.5 |
1000 |
≤3 |
≤5 |
63/54 |
63 |
54 |
5.0 |
1000 |
≤3 |
≤5 |
Technical standard:
Color: Black is the base color, color code on the surface of the duct is distinguished by brown, grey, orange, blue, red, purple, green and yellow. Product supplying is based on requirements.
Appearance: The color and luster is even and unanimous, internal and external wall are smooth without obvious foreign matters and defects, no air bubble, no crack. Internal wall of the silicone duct is closely fused, no split. Both edges are smooth and vertical to th axis. Inside silica gel layer is even distributed. Coil packing is used.
