Specifications
Clear PTFE tubing supplier:1.Self-lubrication
2.Acid and corrosion proof
3.For anto, lead wire, toy motors, instruments...
Property |
Standard |
Property |
Standard |
Relative density |
2.14~2.20 |
Operating temperature |
-80~ +260℃ |
Ensile strength (MPa) |
≥25 |
Oxygen index(%) |
>90 |
Tensile bend strength (MPa) |
≥11 |
Water absorption(%) |
<0.01 |
Elongation (%) |
≥300 |
(x105/℃)21-100℃ |
10 |
Bending elongation |
>300 |
Dielectric strength (kv/mm) |
≥26 |
Shore durometer (D) |
59-63 |
Volume resistance(Ω.cm) |
1x1014 |
Melting point (℃) |
327℃ |
|
|
Product Dimensions:
AWG |
I .D (mm) |
O,D (mm)(S) |
O,D (mm)(T) |
O,D (mm)(L) |
Standard package (meter/coil) |
30 |
0.3±0.10 |
0.80±0.10 |
0.70±0.10 |
0.60±0.10 |
305 |
28 |
0.38±0.10 |
0.88±0.10 |
0.78±0.10 |
0.69±0.10 |
305 |
26 |
0.46±0.10 |
0.96±0.10 |
0.86±0.10 |
0.76±0.10 |
305 |
24 |
0.56±0.10 |
1.16±0.10 |
1.06±0.10 |
0.88±0.10 |
305 |
23 |
0.66±0.10 |
1.26±0.10 |
1.16±0.10 |
0.96±0.10 |
305 |
22 |
0.71±0.10 |
1.31±0.10 |
1.21±0.10 |
1.01±0.10 |
305 |
21 |
0.81±0.10 |
1.41±0.10 |
1.31±0.10 |
1.11±0.10 |
305 |
20 |
0.86±0.10 |
1.66±0.10 |
1.46±0.10 |
1.16±0.10 |
305 |
19 |
0.96±0.20 |
1.76±0.20 |
1.56±0.20 |
1.26±0.20 |
200 |
18 |
1.07±0.20 |
1.87±0.20 |
1.67±0.20 |
1.37±0.20 |
200 |
17 |
1.19±0.20 |
1.99±0.20 |
1.79±0.20 |
1.49±0.20 |
200 |
16 |
1.34±0.20 |
2.14±0.20 |
1.94±0.20 |
1.64±0.20 |
153 |
15 |
1.50±0.20 |
2.30±0.20 |
2.10±0.20 |
1.80±0.20 |
153 |
14 |
1.68±0.20 |
2.48±0.20 |
2.28±0.20 |
2.08±0.20 |
100 |
13 |
1.93±0.20 |
2.73±0.20 |
2.53±0.20 |
2.33±0.20 |
100 |
12 |
2.16±0.25 |
2.96±0.25 |
2.76±0.25 |
2.56±0.25 |
100 |
11 |
2.41±0.25 |
3.21±0.25 |
3.01±0.25 |
2.81±0.25 |
150 |
10 |
2.69±0.25 |
3.49±0.25 |
3.29±0.25 |
3.09±0.25 |
150 |
9 |
3.00±0.25 |
4.00±0.25 |
3.88±0.25 |
3.40±0.25 |
150 |
8 |
3.38±0.25 |
4.38±0.25 |
4.18±0.25 |
3.78±0.25 |
100 |
7 |
3.76±0.25 |
4.76±0.25 |
4.56±0.25 |
4.16±0.25 |
100 |
6 |
4.22±0.25 |
5.22±0.25 |
5.02±0.25 |
4.80±0.25 |
100 |
5 |
4.72±0.25 |
5.72±0.25 |
5.52±0.25 |
5.23±0.25 |
50 |
4 |
5.28±0.30 |
6.28±0.30 |
6.08±0.30 |
5.88±0.30 |
1.0M |
3 |
5.94±0.30 |
6.94±0.30 |
6.74±0.30 |
6.54±0.30 |
1.0M |
2 |
6.68±0.30 |
7.68±0.30 |
7.48±0.30 |
7.28±0.30 |
1.0M |
1 |
7.46±0.30 |
8.46±0.30 |
8.26±0.30 |
8.06±0.30 |
1.0M |
0 |
8.38±0.30 |
9.38±0.30 |
9.18±0.30 |
8.98±0.30 |
1.0M |
PTFE Tube is manufactured by extrusion process. PTFE has excellent chemical resistance, heat resistance, weather resistance features. It is widely used in Science & Technology field, such as in chemistry, instruments, mechanical industries, communications etc.
Packaging & Shipping
1.Our goods are packed in cartons
2.We can accept appointed shipping company or booking ship for client. Tracking the containers until client receive the goods
Features:
1. Operating Temperature: -80℃ to +260℃
2. Excellent anti-corrosion (anti-acid/alkaline/chemical/oil)
3. Standard Color: Clear
We provide sample service, customized service and after-sales service to meet customer requirements.
The Dongguan VAST Insulation Material CO., Ltd is engaged into the manufacturing and selling of insulation materials such as: PVC tubing, PU tubing (soft and hard tube and abnormal shape material). Heat shrinkable tubing, silicone rubber tube PSR series, trend interweave tubing and all kinds of high temperature & high voltage electric wires, which have passed the approval of UL and CUL, and passed the Europe economic common body ROHS environmental protection standard, widely used in the trade of consume, electric, electron, electricity, communication, medical treatment, and got trust and support of all our clients.
Our company has more than ten years of production and developing experiences, with perfect equipment and design ability.
Placing great emphasis on providing superior products, highly personal service, and flexible approach to clients' needs, we desire to establish business cooperation with you, supply our perfect service to you.
1. High tempertature resistant PTFE red tubing from China should be based upon the samples that both sides have confirmed, not restricted by the performance indicators.
2. The company can manufacture High tempertature resistant PTFE red tubing from China which has achieved all the performance indicators, however, the price should be discussed face to face.
