Specifications
High quality tube1.halogen free
2,heat shrinkable
3.insulation
4.high resistance
High quality tube
Features/Applications
Made from specially formulated radiation crosslinked halogen free compounds. Thus it can provide high resistance to tracking and arcing as well as to enhance the insulation properties of bus-bar
in switchgear and substation. Suitable for application in insulating medium voltage bus bars , cable terminations and joints from 11KV to 24Kv.
Halogen free
Minimum shrink temperature: 110°C
Technical data:
Property |
Test Method |
Typical Data |
Tensile strength |
ASTM D 2671 |
≥11.8MPa |
Tensile strength after aging |
ASTM D 2671/120°C, 168hrs. |
≥10MPa |
Longitudinal shrinkage |
ASTM D 2671 |
0 to -10% |
Elongation at break |
ASTM D 2671 |
≥700% |
Elongation at break after aging |
ASTM D 2671/120°C,168hrs. |
≥500% |
Dielectric strength |
IEC 243 |
≥20KV/mm |
Volume resistance |
IEC 93 |
≥1013Ω.cm |
Flammability(Oxygen Index ) |
IEC 4589 |
≥25 |
Water absorption |
ISO 62/23°C,14DAYS |
<0.5% |
