Heat Shrinkable Tubing With Hot Melting Adhesive Cable Cover

Name: Heat Shrinkable Tubing With Hot Melting Adhesive Cable Cover
Brand: VAST
SKU: 108380505
Availability: InStock

Negotiable MOQ: 1 Roll (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

VAST

Material:

Other

Dongguan Weishida Insulation Materials Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name VAST

Material Other

Specification optional

Length optional

Thickness optional

Standard optional

Specifications

with hot melting adhesive cable cover
1.excellent insulating
2.environmental sealing
3.resistant to UV-radiation
tect

Heat shrinkable tubing with hot melting adhesive cable cover

Features/Applications

HRA3 is semi-rigid heavy wall tubing with hot melting adhesive.

Having properties of excellent insulating , environmental sealing

and resistant to impact and abrasion it can protect electrical splices,

cable terminations and joints where electrical Insulation and water

proof are required.Resistant to UV

High electrical insulation

Superior mechanical protection

Minimum fully recovery temperature: 120 °C

Standard color: Black, Red

Property	Test Method	Typical Data
Operating temperature	IEC 216	-55 to +110°C
Tensile strength	ASTM D2671	≥14MPa
Tensile strength after aging	ASTM D 2671/150°C, 168hrs.	≥12MPa
Elongation at break	ASTM D2671	≥400%
Elongation at break after aging	150°C ,168hrs	≥300%
Density	ASTM D792	1.05g/cm³
Longitudinal shrinkage	UL224	0 to -10%
Dielectric strength	IEC243	≥20kV/mm
Volume resistance	IEC93	≥10¹⁴Ω.cm
Eccentricity	ASTM D2671	<30%
Copper stability	ASTM D2671	Pass
Resistance to stress cracking (50°C)	ASTM D1693	No Cracking
Water absorption	ISO 62/23°C,14days	<0.15%
thermoplastic adhesive
Water absorption	ISO 62	<0.2%
Softening point	ASTM D E8	85°C
Peel strength (PE)	DIN 30672	4 N/cm
Copper stability	ASTM D 2671	Non-corrosive
Resistance to fungus and decay	ISO 846	Pass
