HOT!high Quality and High Rate Charge/discharge Rechargeable Super Power Lifepo4 Battery Module 48V30AH Battery Pack LFP LTO LMO

Negotiable MOQ: 20 Packs (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AET

Model Number:

48v30ah

Shenzhen Xinyongfeng Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AET

Model Number 48v30ah

Nominal Voltage Other, 48V

Size Other, 55(diameter)*200(height)

Nominal Capacity 30AH

Material system ( included LFP/ LMO/ NCM/ LTO ) ,dimension ,capacity and performance parameter can be customized.

Item	Basic parameters
	Model	NCM55200S
	Material of Anode/Cathode	Li-NiCoMn /Graphite
	Size (Diameter*Height))	Φ55*H200
	Weight	≤1000g
	Nominal capacity	30Ah
	Nominal voltage	3.6V
	Internal resistance:	≤2mΩ
	Energy density	≥115Wh/kg at 0.2CDC
	Discharge cut-off voltage	2.75V
	Charge voltage	4.2V
	Standard charging	0.2C constant current charge to 4.2V, then constant voltage 4.2V charge till charge current decline to≤0.05C
	Standard discharging	0.2C CC discharge to 2.75V.
	Max .continual charge current	30A(1C)
	Max. continual discharge current	90A(3C)
	Max. Charge/discharge pulse current	180A(6C)
	Operating temperature	Charging: 10~45°C Discharging:-20~55°C
	Storage temperature	Less than 1 year: 0~25°C Less than 3 months: -10~45°C
	High temperature performance	0.5C capacity higher than 98% of nominal capacity at 55°C
	Low temperature performance	0.2C capacity higher than 70% of nominal capacity at -20°C
	Standard charge/discharge cycle life	Cycle life of standard charge/discharge capacity after 1000 cycles greater than 80% of initial capacity
