Item |
Basic parameters |
Model |
12V100AH |
Material of Anode/Cathode |
LiFePO4/Graphite |
Size |
70(T)×340(W)×295(H)(mm) |
Weight |
≤12kg |
Nominal capacity |
100Ah |
Nominal voltage |
12V |
Internal resistance: |
≤8mΩ |
Energy density |
≥130Wh/kg at 0.2CDC |
Volumetric energy density |
≥220WH/L at 0.2CDC |
Discharge cut-off voltage |
8.0V |
Charge voltage |
14.6V |
Standard charging |
0.2C constant current charge to 14.6V, then constant voltage 14.6V charge till charge current decline to≤0.05C |
Standard discharging |
0.2C CC discharge to 8.OV. |
ntinual charge current |
1C |
Max. continual discharge current |
2C |
Max. Charge/discharge pulse current |
4C |
Operating temperature |
Charging: 10~45°C |
Storage temperature |
Less than 1 year: 0~25°C Less than 3 months: -10~45°C |
High temperature performance |
0.5C capacity higher than 98% of nominal capacity at 55°C |
Low temperature performance |
0.2C capacity higher than 70% of nominal capacity at -20°C |
Standard charge/discharge cycle life |
Cycle life of standard charge/discharge capacity after 2000 cycles greater than 80% of initial capacity |
We are unique ups batterymanufacturer of high capacity lipo battery from 10AH to 300AH for cell, diffrent types of battery series which contain LFP, LMO ,NCM, LTO .We can customize products according to your performance parameters.
Product Characteristics:
· Soft pack, barren liquor ,excellent security, need not safety valve
· Large capacity . long cycle life, high energy density
· Low internal resistance, low self-discharge rate
· Superior performance in rate discharging
· 360 degree in any display, high space utilization
· Wide operating temperature : -20-55 degree
Applications:
- EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus .
- · Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
- · Power Supply: communication base station power supply, UPS, emergency power supply etc.
