Specifications
24V 100ah lipo battery for ev/ hev/ electirc scooter/UPS- 3000 cycles life
- <25kg
- 120wh/kg;220wh/L
- ROHS/CE/MSDS/UN38.3
24V 100ah lipo battery for ev/ hev/ electirc scooter/UPS
Item |
Basic parameters |
Model |
24V100AH |
Material of Anode/Cathode |
LiFePO4/Graphite |
Size |
168(T)×340(W)×295(H)(mm) |
Weight |
About 23Kg |
Nominal capacity |
100Ah |
Nominal Voltage |
24V |
Internal resistance |
≤8mΩ |
Energy density |
≥120Wh/kg at 0.2CDC |
Volumetric energy density |
≥220WH/L at 0.2CDC |
Discharge cut-off voltage |
16V |
Charge voltage |
29.2V |
Standard charging |
0.2C constant current charge to 29.2V, then constant voltage 29.2V charge till charge current decline to≤0.05C |
Standard discharging |
0.2C CC discharge to 16V. |
Low temperature performance |
0.2C capacity higher than 70% of nominal capacity under -20°C |
High temperature performance |
0.5C capacity higher than 98% of nominal capacity under 55°C |
Standard charge/discharge cycle life |
Cycle life of standard charge/discharge capacity after 3000 cycles greater than 80% of initial capacity |
Max .continual charge current |
100A ( 1C) |
Max. continual discharge current |
200A (2C) |
Max. Charge/discharge pulse current (10S) |
400A (4C) |
Operating temperature |
Charging: 10~45°C, Discharging:-20~55°C |
Storage temperature |
Less than 1 year: 0~25°C Less than 3 months:-10~45°C |
Features:
1. Good cell consistency, High energy density.
2. Low internal resistance, low thermal generated and high safety performance.
3. Good high temperature performance.
4. High capacity, low self-discharge rate and long cycle life.
5. Dimension and type(capacity type and ratio type) can be customized.
Applications:
1. EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus, recreational vehicles, chill cars.
2. Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
3. Power Supply: communication base station power supply, utility power supply, communication industry,
emergency power supply and other system standby power etc.
What we can do:
1. All of our products have proceeded comprehensive testing before shippment;
2. Support imprint your logo on products;
3. OEM orders are warmly welcome!
Warranty and Return:
1. All products have been tested before ship out;
2. All products have 1 year warranty. ( We will Changing or Refunding our products if problems appearanced in 1 year, in the case of correct operation according to the technical specification.)
3. We own the best after-sale service. If any problems happen, our team will do our best to solve for customers.
