2*5 bidi SFF optical module
Product Description
Model Numebr |
NTR-9612 |
Brand |
NETON(OEM/ODM is ok) |
Encapsulation |
SFF(2*5) |
Function Type |
Optical Transceiver |
Data Rate |
Up to 125Mb/s |
Fiber Mode |
Single Mode/SM |
Transmission |
Single Fiber |
Wavelength |
1310nm/1550nm |
Distance |
20Km on 9/125μm SMF |
Connector |
Single SC |
Average Optical Output Power |
-10~ -3 dBm |
Extinction Ratio |
>9dB |
Eye Pattern |
OK |
Receiver Sensitivity |
<-23 dBm |
Loss of Signal Assert |
<-23 dBm |
Loss of Signal Deassert |
>-33 dBm |
Saturation Power |
>-3 dBm |
Supply Voltage |
3.3V |
Supply Current |
≤210 mA |
Operating Temperature |
Com. 0~+70℃ |
Digital diagnostic monitoring(DDM) |
YES |
Compatible |
MSA/ SFF-8472 v9.3 |
Dimension |
49.1*14.75*10.0mm |
Weight |
0.03Kg |
Same Serial Products Order Information
Type |
Data rate(Mbps) |
Distance |
Laser Transmitter |
Encapsulation |
Supply Voltage |
NTR-9612 |
1250 |
20Km |
1310nm /1550nm |
2*5 SFF,SC |
+3.3V |
NTR-9613 |
1250 |
20Km |
1550nm /1310nm |
2*5 SFF,SC |
+3.3V |
NTR-9614 |
1250 |
40Km |
1310nm /1550nm |
2*5 SFF,SC |
+3.3V |
NTR-9615 |
1250 |
40Km |
1550nm /1310nm |
2*5 SFF,SC |
+3.3V |
NTR-9618 |
1250 |
80Km |
1490nm/1550nm |
2*5 SFF,SC |
+3.3V |
NTR-9619 |
1250 |
80Km |
1550nm/1490nm |
2*5 SFF,SC |
+3.3V |
Products Details
All our materials must pass strict quality check before their using, And we can also sell you the TOSA/ROSA and other accessories produced by myself.
Providing Customized products and sevices are our strongest advantages. Area of Military, Smart Grid,Rail Transit, Security&Protection are using Neton's optical transceiver.
155Mbps BIDI SFP optical module 1.25Gbps BIDI SFP optical module
GEPON ONU SFP optical module DC~500Kbps 20Km 1x9 optical transceiver
10G SFP+ LR optical transceiver 3G HD-SDI BIDI 1X9 optical transceiver
Chengdu Neton Inc.is a professional optical transceivers manufacturer in China. Our products cover SFP, 10G SFP, XPON, CWDM SFP,BIDI SFP,HD-SDI, 1x9, SFF modules for over 14 years.
Neton have 1350m2standard factory, exceed 800 m2 of antistatic and dust-proof plant. Over 40 technicians to support the research and development of our products.
Neton achieved to be a public company(Stock Code: 430473) in Jan. 2014
In order to supply high quality transceivers, 100% tests will be doing before shipping. The tests including high&low temp. Circulation,assembly check,IC check,finished products examine. To guarantee the perfect compatiblilities, we also do 100% compatible testing before shipping. The compatible brand including HUAWEI,CISCO,3COM,ALCATEL,NEXUS, BROCADE...
The main equipment are as follows.
Neton believe High quality from advanced equipment and strict administration system. Neton have passed ISO9001:2000, TUV, UL, FDA, CE,RoHs.
All packages are satisfied your requires firstly. Neton packages are using anti-stastic and shake-proof materials. Usually, The details are as the table below.
SFF Quantity |
Carton Dimension |
Gross Weight |
≤50 pcs |
22*17*11 cm |
2 Kg |
≤100 pcs |
34*20*11 cm |
4 Kg |
≤ 500pcs |
54*34*34 cm |
17 Kg |
1.What is the warranty for your optical transceivers?
All our products with strict quality control. Optical transceivers have 1 year warranty and 3-5 years for MTBF. Free for maintaining within warranty period. In fact, Our repair rate is almost zero.
2.Are your optical transceivers compatible with Cisco equipment?
Yes.Our optical transceivers can be compatible with Cisco devices.We must 100% test the compatible abilities before leaving our plant as your requires, compatible brand including Cisco,Huawei,Hp,WTD,H3C,JUNIPER,ALCATEL LUSENT,FIBERHOME and son on.
3.I placed an order,who do i call to get tracking information?
Our colleagues of shipping will send you the tracking information immediately after shipping. You can also get the tracking messages from your sales servicer.
4.How do I know NETON parts are good?
We currently are an approved vendor/a gold supplier for Alibaba. We have a number of testing facilities at our disposal and have on-site counterfeit screening capabilities.Our reputation has been built on providing quality parts and customer service you can count on.
5. What's your best advantage in the optical modules line?
achieve various customized requires is our favourate advantage. Because over 20 excellent technicials act as our strong backers.
6.What's your main products?
Our main products are optical transceiver modules, like 1x9, SFP,XFP.
And we can produce all datarate series of modules from DC~2M, 2M~622M,622M~2.5G to 2.5G~40G,
and all kinds of encapsulations from 1x9, SFP,XFP, SFP+ to PON, GPON,GEPON even copper connector and metal 1x9, and WDM from CWDM to DWDM are acceptable,
and single/double/triple transceiver module,single/double/triple transmitter module, single/double/triple receiver module for your various demands.
More information, please feel free to contact us!
