1250M 1310NM 10KM SC GBIC Gbics/Transceivers
Product Discription
N eton’s NTR-76XX GBIC transceiver modules are the perfect solution for high-speed communication networks.
As a professional manufactory of optical module Neton provides customer reliability, robustness and high performance whole line transceiver products using for Telecom, Datacom, and other data communication applications.
Neton’s NTR-76XX GBIC transceivers support data rates up to 1.25Gbps. These modules are fully compliant with the Gigabit Interface Converter Specification Revision 5.5 and Gigabit Ethernet standard as specified in IEEE802.3z.
The family provides a uniform form factor for a wide variety of standard connections to transmission media. The converters can be inserted or removed from a host chassis without removing power from the host system.
NTR-76XX has been designed to provide good immunity to RF electromagnetic fields. Key components are all packaged inside a metallized plastic frame with metal cover to guarantee
excellent EMC/EMI performance.
Order Information
Type |
Data rate(Mbps) |
Description |
Laser Transmitter |
Encapsulation |
Supply Voltage |
Data Level |
NTR-7631 |
1250 |
SM, 10Km,OC-24 |
1310nm FP Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
Type |
Data rate(Mbps) |
Description |
Laser Transmitter |
Encapsulation |
Supply Voltage |
Data Level |
NTR-7631 |
1250 |
SM, 10Km,OC-24 |
1310nm FP Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
NTR-7632 |
1250 |
SM, 20Km,OC-24 |
1310nm FP Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
NTR-7634 |
1250 |
SM, 20Km,OC-24 |
1310nm FP Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
NTR-7654 |
1250 |
SM, 40Km,OC-24 |
1550nm DFB Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
NTR-7656 |
1250 |
SM, 60Km,OC-24 |
1550nm DFB Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
NTR-7658 |
1250 |
SM, 80Km,OC-24 |
1550nm DFB Laser Diode |
GBIC,SC |
+5V/+3.3V |
PECL |
Product Features
• 1310nm or 1550nm wavelength Laser Transmitter
• Compliant with gigabit interface converter specification rev.5.5
• Compliant with proposed specifications for
• IEEE802.3z Gigabit Ethernet (1000Base-SX).
• Up to 80Km on 9/125µm SMF
• +3V~+5V power supply
• Hot-Pluggable
• Class 1 eye laser safety
• Excellent EMI and ESD protection
• Low power dissipation
Application
• Switch to switch interface
• High speed 1/0 for file servers
• Bus extension applications
1x9 Optic Transceiver Module
Product Series---SFP Transceiver Module
1.What is the warranty for your 1x9 optical modules?
All our products with strict quality control.1x9 modules have 1 year warranty and 3-5 years for MTBF. Free for maintaining within warranty period. In fact, Our repair rate is almost zero.
2.Do you ship internationally?
Yes.We can ship anywhere you would like.If your order is paid by T/T, and Westem Union we can ship it via our delivery forwarder or on your shipping account number ,to ensure you are getting the best rates and this allows you to handle the export/import taxes.
3.I placed an order,who do i call to get tracking information?
Our colleagues of shipping will send you the tracking information immediately after shipping. You can also get the tracking messages from your sales servicer.
4.How do I know NETON parts are good?
We currently are an approved vendor/a gold supplier for Alibaba. We have a number of testing facilities at our disposal and have on-site counterfeit screening capabilities.Our reputation has been built on providing quality parts and customer service you can count on.
5. What's your best advantage in the optical modules line?
achieve various customized requires is our favourate advantage. Because over 20 excellent technicials act as our strong backers.
6.What's your main products?
Our main products are optical transceiver modules, like 1x9, SFP,XFP.
And we can produce all datarate series of modules from DC~2M, 2M~622M,622M~2.5G to 2.5G~40G,
and all kinds of encapsulations from 1x9, SFP,XFP, SFP+ to PON, GPON,GEPON even copper connector and metal 1x9, and WDM from CWDM to DWDM are acceptable,
and single/double/triple transceiver module,single/double/triple transmitter module, single/double/triple receiver module for your various demands.
