TX:155Mbps RX:1250Mbps 1550nm FP 20Km SM of 1X9 Bi-Di multirate
Product Description
N eton’s NTR-2621X/2261X series of transceiver modules are the perfect solution for High-speed communication networks.
The transceiver modules may use different data rates (or data level) between transmitter and receiver, support data rates up to 1250 Mbps. These modules are fully compliant with the Multi- sourced 1x9 protocol.
The NTR-2621X/2261X series is high performance module for single fiber communications by using 1310nm/1550nm transmitter and 1550nm/1310nm receiver. The transmitter section uses a DFB (or FP) laser diode and is a class 1 laser compliant
according to International Safety Standard IEC-825. The receiver section uses an integrated 1310 nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. APECL logic interface simplifies interface to external circuitry.
Order Information
Type |
Data rate(Mbps) |
Description |
Laser Transmitter |
Encapsulation |
Supply Voltage |
Data Level |
NTR-26217 |
Tx:1250 Rx:155 |
SM 60Km |
1550nm DFB Laser Diode |
1×9SC,FC,ST |
+5V/3.3V |
PECL |
Product Features
• Single Fiber Bi-Directional Transceiver
• 1310nm FP and 1550nm FP(or DFB) Laser Diode Transmitter
• Distance Up to 60km
• Industry Standard 1 x 9 Footprint
• Single 3.3V,5V,3.3V/5Vpower supply
• SC /FC/ST single receptacle or Pigtail SC/PC,ST/PC, FC/PC optional
• Wave Solderable and Aqueous Washable
• Class 1 Laser International Safety Standard IEC-825 Compliant
• Optical Isolation > 30 dB
Application
WDM 1250 Mb/s Links
SONET/SDH Equipment Interconnect
Digital video transmission
Same Serial Products Order Information
Type |
Data rate(Mbps) |
Description |
Laser Transmitter |
Encapsulation |
Supply Voltage |
Data Level |
NTR-26212 |
Tx:1250 Rx:155 |
SM 20Km |
1310nm FP Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
NTR-22613 |
Tx:155 Rx:1250 |
SM 20Km |
1550nm FP Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
NTR-26214D |
Tx:1250 Rx:155 |
SM 40Km |
1310nm DFB Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
NTR-22615 |
Tx:155 Rx:1250 |
SM 40Km |
1550nm DFB Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
NTR-26217 |
Tx:1250 Rx:155 |
SM 60Km |
1550nm DFB Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
NTR-22616 |
Tx:155 Rx:1250 |
SM 60Km |
1310nm FP Laser Diode |
1×9SC,FC,ST |
+5V/+3.3V |
PECL |
1x9 Optic Transceiver Module
Product Series---SFP Transceiver Module
1.What is the warranty for your 1x9 optical modules?
All our products with strict quality control.1x9 modules have 1 year warranty and 3-5 years for MTBF. Free for maintaining within warranty period. In fact, Our repair rate is almost zero.
2.Do you ship internationally?
Yes.We can ship anywhere you would like.If your order is paid by T/T, and Westem Union we can ship it via our delivery forwarder or on your shipping account number ,to ensure you are getting the best rates and this allows you to handle the export/import taxes.
3.I placed an order,who do i call to get tracking information?
Our colleagues of shipping will send you the tracking information immediately after shipping. You can also get the tracking messages from your sales servicer.
4.How do I know NETON parts are good?
We currently are an approved vendor/a gold supplier for Alibaba. We have a number of testing facilities at our disposal and have on-site counterfeit screening capabilities.Our reputation has been built on providing quality parts and customer service you can count on.
5. What's your best advantage in the optical modules line?
achieve various customized requires is our favourate advantage. Because over 20 excellent technicials act as our strong backers.
6.What's your main products?
Our main products are optical transceiver modules, like 1x9, SFP,XFP.
And we can produce all datarate series of modules from DC~2M, 2M~622M,622M~2.5G to 2.5G~40G,
and all kinds of encapsulations from 1x9, SFP,XFP, SFP+ to PON, GPON,GEPON even copper connector and metal 1x9, and WDM from CWDM to DWDM are acceptable,
and single/double/triple transceiver module,single/double/triple transmitter module, single/double/triple receiver module for your various demands.
