Product Details
| Place of Origin: | Sichuan, China | Brand Name: | NETON | Model Number: | NTR-2234 |
Product Description
155Mbps 1x9 SM Transceiver Module new products anti-jamming transceiver module
Product Description
Neton ’s NTR-2234IVMP(ST J) series of transceiver modules are the perfect solution for high -speed communication networks.
The transceiver modules support data rates up to 155Mbps. These modules are fully compliant with the Multi-sourced 1×9 protocol.
The transceiver module supplies the Differential PECL of 3.3V Voltage and provides the system designer with products to implement a range of FDDI and ATM designs at the
100Mbps / 125Mbps rate and SONET/OC-3, SDH/STM-1 for Telecommunication.
Industry level transceiver module which operating at -40℃ to +85℃.
Order Information
Type | Data rate(Mbps) | Description | Laser Transmitter | Encapsulation | Supply Voltage | Data Level |
NTR-2234IVMP(ST J) | 155 | SM 40Km | 1310nm FP Laser Diode | 1×9ST | +3.3V | PECL |
Product Features
Multi-sourced 1 × 9 pin packaged
1310nm FP Laser Transmitter
ST double receptacle
Metal case
Excellent EMI and ESD protection
Up to 40Km with 9/125μm SMF
Single 3.3V power supply
PECL signal input and output
Wave solderable and washable with process plug inserted
Temperature ranges:
— -40°C to +85°C for industry level
Application
ATM equipments
SONET/OC-3,SDH/STM-1 equipments
100Mbps Fast Ethernet equipments
1x9 Optic Transceiver Module
Product Series---SFP Transceiver Module
1.What is the warranty for your 1x9 optical modules?
All our products with strict quality control.1x9 modules have 1 year warranty and 3-5 years for MTBF. Free for maintaining within warranty period. In fact, Our repair rate is almost zero.
2.Do you ship internationally?
Yes.We can ship anywhere you would like.If your order is paid by T/T, and Westem Union we can ship it via our delivery forwarder or on your shipping account number ,to ensure you are getting the best rates and this allows you to handle the export/import taxes.
3.I placed an order,who do i call to get tracking information?
Our colleagues of shipping will send you the tracking information immediately after shipping. You can also get the tracking messages from your sales servicer.
4.How do I know NETON parts are good?
We currently are an approved vendor/a gold supplier for Alibaba. We have a number of testing facilities at our disposal and have on-site counterfeit screening capabilities.Our reputation has been built on providing quality parts and customer service you can count on.
5. What's your best advantage in the optical modules line?
achieve various customized requires is our favourate advantage. Because over 20 excellent technicials act as our strong backers.
6.What's your main products?
Our main products are optical transceiver modules, like 1x9, SFP,XFP.
And we can produce all datarate series of modules from DC~2M, 2M~622M,622M~2.5G to 2.5G~40G,
and all kinds of encapsulations from 1x9, SFP,XFP, SFP+ to PON, GPON,GEPON even copper connector and metal 1x9, and WDM from CWDM to DWDM are acceptable,
and single/double/triple transceiver module,single/double/triple transmitter module, single/double/triple receiver module for your various demands.
