TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube

TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube thumbnail-1
TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube thumbnail-2
TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube thumbnail-3
TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube photo-1
TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube photo-2
TUV/UL Approved 1500mm 30W 2016 New Led 8 Tube photo-3
US$ 33 - 37 MOQ: 10 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD2835
Warranty(Years):
5
Input Voltage(V):
AC100-277V
Contact Supplier Request Quote Chat Now
Shenzhen Shinelong Technology Corp., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD2835
Warranty(Years) 5
Input Voltage(V) AC100-277V
Lamp Power(W) 30
Place of Origin Guangdong, China
Brand Name SHINELONG
Model Number Other, SL-T85X30-528-X



2011 new led 8 tube SPECIFICATION

Absolute Maximum Rating at TA=25°C

Parameter

Absolute Maximum Rating

Rated Input Voltage

AC90V ~ AC270V

Operating Voltage

DC36V ~ DC40V

Operating Current

Constant 17mA

Electrostatic Discharge

1500 V

Operating  Temperature

-20 ~ +50 °C

Storage Temperature

-30 ~ +50 °C

 Material

Aluminum + Striped /Transparent/Frosted PC cover

Power consumption

30W

Led Qty

528 PCS

Luminous Flux(Typ)

3000-3100LM

Color temperature

WW:3000-3500-4000K;PW:4500-5000-5500K; CW:>6000K

CRI

70Ra

Viewing angle

120°

Power Factor

>95

Life Time

30,000-50,000 H

Applications

1. Local Lighting: House / Institutional building / Conference Meeting  room/Showroom/Showcase

2.Commercial Lighting: Super-market / Department store/shops

3. Public Place Lighting: School / University / Hospital / Hotel

Remarks: All the technical data was tested in Shinelong laboratory





The advantages of SHINELONG products

 •Patent design for tube shape and product mix

•Isolated power supply and can be replaced easily by hand

•High Illumination 0.06W SMD LED and low light decay

•Patent turntable end cap for different light emitting directions

•Constant LED forwarder current during tube operating

•Temperature difference less than 10°C between inside and outside

•TUV, UL, CE, RoHS approved





The advantages of SHINELONG factory:

•Complete production lines, including SMD LED, Tube series, Flexible LED stripe series, Mould making and Plastic laminating..

•Advanced equipments for production and testing. For example YAMAHA SMT and American HELLER solder reflow.

•ERP system for factory management.

•Professional production , R&D and SALSE team.

•Big work shop and large production capacity(500,000PCS tubes/month)

•Recyclable, SHINELONG can take back or replace the products after being used
