Product Details
| Place of Origin: | Shandong, China | Brand Name: | TAILONG | Model Number: | TAILONG-WS-001 |
Product Description
Hotel school steel structure warehouse drawings :
NO | NAME | Specification of Hotel school steel structure warehouse drawings |
1 | Main structure | welding H steel or hot rolled H steel,all bolts connection straight cross-section orvariable cross-section
|
2 | Purlin: | C section channel or Z section channel |
3 | Roof cladding | corrugated steel sheet or sandwich panel with fiber glass wool, EPS, rock wool, PU |
4 | Wall cladding | corrugated steel sheet or sandwich panel with fiber glass wool, EPS, rock wool, PU |
5 | Column barcing | angle steel or H section steel or steel pipe |
6 | Knee brace | angle steel |
7 | Roof ridge | corrugated steel sheet |
8 | Wrapping cover | color steel sheet |
9 | Roof gutter | color steel sheet |
10 | Rainspout | PVC pipe |
11 | Design | According to your drawings or some details needed. |
12 | Fabrication | Strictly fabricate every member based on the drawings confirmed. |
Production process of Hotel school steel structure warehouse drawings
Name | Specification of Hotel school steel structure warehouse drawings |
Length | Single/double/muti -slope |
Width | Single/double/muti-span |
Height | Single floor/ double floors |
Column | Q235 Q345 welding H section steel |
Beam | Q235 Q345 welding H section steel |
Purlin | Q235 c channel or z channel |
Knee brace | Q235 angel steel |
Vertical and transversal support | Q235 angel steel, round bar, steel pipe |
Tie bar | Q235 steel pipe |
Brace | Q235 round bar |
Cladding system | EPS, ROCK WOOL, PU,single color steel corrugated sheet |
Partition wall | EPS, ROCK WOOL, PU,single color steel corrugated sheet |
Ventilation | Ventilator |
Door | color steel silding door or electric rolling gate |
Gutter | Stainless steel or color steel corrugated sheet |
Downpipe | PVC |
High strength bolt |
|
Anchor bolt |
|
Live load on roof | In 120kg/sq |
Wind resistance grade | 12 |
Earthquake-resisitance | 8 |
1.All of the steel column and beams ends and plates will be packed by the blanket to protect them from the crash in the container durning the shippment.
2.To make the loading more effieciently and saving the delivery cost, 40OT is prefered to loading the steel frames.
3.All the wall and roof panels will be filmed by two sides and fixed stably in the 40HQ container.
4.All the windows and doors will be protected by the bubble rapping papers and fixed stablely in the container.
We will send our engineer to your construction site to guide you.
This is Tracy comes from Qingdao Tailong Steel Structure Co,. Ltd , we are the manufacturer and specialized in steel structure lines since 2003 , we have imported for 13years to all over the world,there is the professional engineer design team and salesmen to service for you , you will get the good design, high quality ,best price and service from here.
Choose Tailong, we will make your building more strong and beautiful.
we have got the CE certificated for the light steel framing system. we can supply all the finishing materials that have the CE certificate.
You can provide us your drawing ,and we will produce as your drawings. Or we can design as your requirements if you don’t have a clear plan. We will provide our plans according to destination condition , people preference ,strong and durable use, economic cost, environment protection, etc.
we can supply the supervisor and engineer if client need.
1.why choose us?
we have professional design team ,sales team, high quality,best quality,best price and service, what is more ,your building will more strong and beautiful.
2.you need to supply the inforation as follows:
the size:length*width*height
the max wind-speed of construction site
the max snow-load of construction site(if have)
3.How to install the building?
we will send you the construction drawing ,and also our engineer will help you to install the project
If you have any question ,pls contact to me.
Qingdao Tailong Steel Structure Co,. Ltd
Mobile: +8618753272963
Skype:tracy.zhang675
Tracy
