Welding Electrodes of Stainless Steel

Welding Electrodes of Stainless Steel thumbnail-1
Welding Electrodes of Stainless Steel photo-1
Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
India
Brand Name:
RATNA 18/8/5
Model Number:
AWS A5.4: E307-16 (Nr.)
Contact Supplier Request Quote Chat Now
Raajratna Electrodes Private Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Pipavav/Mundra/Mumbai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin India
Brand Name RATNA 18/8/5
Model Number AWS A5.4: E307-16 (Nr.)
Material Stainless Steel
Application Specially designed for joining ferrite to austenitic steels.

Welding Electrodes of Stainless steel Welding Electrodes of Stainless steel

RATNA 18/8/5

A basic coated austenitic stainless steel Electrode of the 18Cr-8Ni-6Mn.

CLASSIFICATION         : AWS/SFA-5.4: E 307-16 (Nr.), DIN E 18 8 Mn B 20
                                          IS-5206: E 18.8MnR 26

APPROVAL                   : RDSO

CHARACTERISTICS    : A medium heavy coated austenitic stainless steel electrodes with stainless steel core wire give weld deposition of 18Cr-8Ni-5Mn and weld metal has excellent heat resistance up to 900°C and corrosion resistance from atmosphere, sea water and weak acids.


APPLICATION              :
1) It is easy to operate in all position at low currents and for joining and surfacing applications to enhance resistance to impact and abrasion and also for buffer layers on variety of steels.
2) Specially designed for joining ferrite to austenitic steels, armour plates, austenitic Manganese steels (12% Mn ), Heat Resistance steels, dissimilar materials for buffer layers etc.

RE-DRY CONDITION     : Re-Dry the electrode at 250°C for 1 hrs before use.


ALL WELD CHEMICAL COMPOSITION %
C Mn Si S P Cr Ni
0.14 max. 5.00-8.00 1.00 Max 0.030 Max 0.040 Max 18.00-21.50 9.00-10.70
ALL WELD MECHANICAL PROPERTIES :
UTS
(N/mm²)		 EL %
(l=4d)		 CHARPY “V” NOTCH IMPACT AT HARDNESS
590-670 30-40 +200°C : 80-120 J AS WELDED 200 BHN AS WORK 500 BHN

DIMENSION, CURRENT CONDITION & PACKING DATA
Size(mm) (Dia) Size(inch) (Dia) Current Condition (DC+/AC) Amps No. of Pcs./pkt. No. of Pcs./Case
2.50/ 2.40 X 350 3/ 32” X 14” 50-80 90 720
3.15/ 3.20 X 350 1/ 8” X 14” 75-100 60 480
4.00 X 350 5/ 32” X 14” 110-140 40 320
5.00 X 350 3/ 16” X 14” 150-180 25 200
