20-120hp Farm Tractor

20-120hp Farm Tractor thumbnail-1
20-120hp Farm Tractor photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Shandong Changlin Deutz-Fahr Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Certificate Other, 3c
Brand Name changlin deutz fahr
Model Number SH 1004
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

streamline design, new model new design, apply Italy same deutz fahr technology, more powerful, more durable

Model

SH1000/SH1004

                                                      Engine

Engine Power KW/HP

73,5 / 100

Engine Type (Cyl, T/NA)

4 ,Turbo charger /Natural Aspirated

Rated Speed (rpm)

2300

Engine Torque (Nm @ engine rpm)

380,1600~1800

Specific Fuel Consumption (L/h)

≤21.44

Emission Regulation availability (Euro I,II,II)

stageⅡ

Cooling type

Water cooling

Engine Displacement(L)

4.75

Air filter type

Oil Bath

Fuel tank capacity (litres)

126

Exhaust pipe (Vertical/Horizontal)

Vertical

Engine starter (kw)

3.8

Alternator (V/w)

14/900

                                              TRANSMISSION

Type of clutch

Single, Dry

Total gears

16 F + 8 R

Synchronized Gearbox (YES/NO)

NO

Min-Max speed

0.463--34.873F / 0.622-10.798R

Differential lock (limited slip/100% lock)

100% lock

Max Drawbar Pull 2WD/4WD (KN)

28.8/34.65

Type of rear final drive (PLanetary, cascade),

Planetary/3

                                                      PTO

Pto speeds PT(rpm)

760 / 1000

PTO speed @ engine speed

760 / 1000@2300

PTO engagement

8XΦ38/6XΦ35/21XΦ35

PTO independent clutch (YES/NO)

YES

PTO shaft splines

8

                                             HYDRAULIC SYSTEM

Outlets pump type

gear pump

Max pressure (bar)

175

Max pump delivery @ engine rpm(ml/r),(rpm)

20/ 2000

Outlets valves function (Kick-out, Detent, Float)

Float

                                              TECHNICAL DATA

Overall size 2WD (LxWxH) / mm

4290x2100x2810

Overall size 4WD (LxWxH) / mm

4290x2100x2810

Max height with ROPS

2790

Max height with CABIN / mm

2860

Rear Wheel track 2WD / mm

1610

Front Wheel track 2WD / mm

1510

Front Wheel track 4WD / mm

1610

Rear Wheel track 4WD / mm

1608,1692,1796,1892,1996(Non-stepless adjustment)
