5KW MPPT 3 Phase Solar Hybrid Wind Grid Tie Inverter

Jiangxi Mingwei Electronic Co., Ltd.
5KW MPPT 3 Phase Solar Hybrid Wind Grid Tie Inverter thumbnail-1
5KW MPPT 3 Phase Solar Hybrid Wind Grid Tie Inverter photo-1
US$ 300 - 600 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
OEM
Model Number:
SDS-5000W
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen/at your choices
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Brand Name OEM
Model Number SDS-5000W
Output Power Other, 5000W
Output Type Triple
Size 640*375*285mm
Weight 28KG
Input Voltage DC 100~500V
Output Voltage 200~400V
Type DC/AC Inverters
Output Frequency 50HZ/60HZ
Output Current 13.6A

5KW MPPT 3 phase solar hybrid wind grid tie inverter

Product Description



1.Specification

ModelSDS-5000W
Isolation typeTransformerless
DC InputMPPT Voltage RangeDC100~500V
Max.DC Voltage500VDC
Rated Input voltage180V
Control SystemMPPT
String of MPPT1
AC OutputRated Output Power5000W
Max.AC Output Current22.7A
Rated Grid voltageAC 185~264V
Grid Frequency50Hz/60Hz(Adjustable)
Phases1 phase 2 wire
Power Factormore than 0.95
Current THDat rated power and in the sine wave less than 3%
Control SystemMPPT
Anti-islandingless than0.5 sec
Output Overload100%
Efficiencymore than 99%
StructureProtection ClassIP20
Cooling systemNatural cooling
NoiseLess than 40dB
Data InterfacesExternal RS232C/RS485
DisplayLCD
Dimensions(W*H*D)640*375*285MM
Weight28KGS
ProtectionInverterOvervoltage of Input,Short of Output,Over-load,Protecting inverter from overheating,short of fuse,preventing DC output
GridAnti-islanding(IEEE 1547),over/unver voltage of grid,over/under frequency of grid.
EnvironmentEnvironmentNo corrosion gas,flammable gas,oil mist,dust etc.
Operation temperature-20 °C~50 °C
Stored temperature  -20 °C~65°C
Relative humidity 0~100%(Do not wet with dew)
 Warranty3-years quality warranty
 CE-Standards compliedCE-Standards Complied:EN61000-6-2,EN61000-6-4(EMC),EN61558-1,EN61558-2-17,EN50178,EN61000-1
 CertificationsCE,VDE0126-1,AS4777,AS3100,G83/1,G59,ISO9001:2000

2.Pictures



5KW MPPT 3 phase solar hybrid wind grid tie inverter

3.Certifications

 5KW MPPT 3 phase solar hybrid wind grid tie inverter





Our Services





-Fast make response for your inquiry in 8 hours

-Fast delivery your samples in 3 days

-Fast ship your goods in 7 days



21000 squre meters factory

200 skilled workers work 8 hours 5 days each week

8 professional foreign trade salesladies

100% sincerely service for you

Packaging & Shipping



5KW MPPT 3 phase solar hybrid wind grid tie inverter



 5KW MPPT 3 phase solar hybrid wind grid tie inverter


Company Information



Mingwei Corporation, founded in 2003,is recognized as the leading manufacturer of industrial switching powelies in China. Our self-invested new factory is located in Jiangxi Ruijin, covering an area of 21000m²,factory building 20000m².The products include AC/DC&DC/DC standard, PFC, open frame, battary charger, din rail, LED driver and custom-design switching power supplies, over 5000 models showing greating flexibility. “Mingwei” has been a famous brand in China, and incresingly well-known in the world market.

 5KW MPPT 3 phase solar hybrid wind grid tie inverter



                                         WELCOME TO VISIT OUR FACTORY!
