Specifications
welding flux TY-SJ301Specification:
EN760 SA CS 1 89 AC H5
AWS A5.17 F6A0-EL8 F7A2-EM12K
high quality and factory price
welding flux TY-SJ301
1.Chemical composition(%)
| SiO2+TiO2 | CaO+MgO | Al2O3+MnO | CaF2 | S | P |
| 30-40 | 5-10 | 25-30 | 5-13 | ≤0.05 | ≤0.05 |
2.Chemical Composition of Deposited Metal
| Wire | C | Si | Mn |
| EL8 | 0.05-0.10 | 0.35-0.50 | 1.2-1.5 |
| EM12K | 0.05-0.10 | 0.35-0.50 | 1.4-1.6 |
3.Typical deposited metal mechanical property
| Matched wire |
Standard |
Yield Strength ó s MPa |
Tensile Strength ó b MPa |
Elongation δ 5% |
AKV(J) |
| EL8 | F6A0-EL8 | ≥350 | ≥ 420 | ≥22 | 40(0°c) |
| EM12K | F7A2-EM12K | ≥410 | ≥ 500 | ≥30 | ≥60 (-20°c) |
4.Application
Butt and flat fillet welding of miniature LPG tanks, ships, vehicles, agricultural implements, machinery, boilers, bridges, structural steels.
5.Characteristics
TY-SJ301 is an agglomerated calcium- silicate type welding flux.
Metallurgical behavior: High silicon pick-up is obtained. When the manganese content in wire is less than 1.5%, also a manganese pick up.
Grain size:10 to 60 mesh
Basicity:1.0(BIIW)
Regularly shaped welds are deposited without reduction og arear or interface notches. Slag detachability is good. A short slag is produced, thus allowing circumferential welding on small -diameter workpieces without the risk of uncontrolled slag.
The production of large pipes(especially spiral pipe welding) is typical application for this flux.
Relatively high manganese pick-up is obtained, thus allowing the flux to be used with wires with a low Mn content.
As the bulk density is low, So is the consumption rate.
Damp flux should be re-dried at 300-350°c for 2 hours. Rust, grease and moisture on the weldment should be removed before welding.
5. package
25kg/kraft paper bag, then 40 bags/pallet. pne pallet net weight is 1 ton
6.our servise
1.Samples: Free samples are available for you. We will send you free samples as your requirements.
2.If you have any questions, we can explain to you immediately.
3.We promise we will supply our best quality with factory price.
4.We promise the goods can be delivered on time and will not bring any trouble to you.
5.When you use our products, we can guide you how to use them.
6.We will try our best to servise you well as your requirements.
7.our factory
Qingdao Hua Sheng Ming Hao International Trade Co.,Ltd is located in Qingdao economic development district which is a leading professional manufacturer of welding consumables in China.
Our company can produce 7 serious of welding electrodes of carbon steel, low alloy steel, heat-resistant steel, low temperature steel, stainless steel, surfacing cast iron as well as gas shielding solid welding wire, flux cored welding wires, submerged- arc welding wire, argon arc welding wire, flux and so on covering 200kinds of welding materials.
