Home > Instruments & Meters > Test Instrument > Test Machine > JGTM-06012 Test Paper and Paperboard Meter/paper Folding Endurance Testing Instrument

JGTM-06012 Test Paper and Paperboard Meter/paper Folding Endurance Testing Instrument

Name: JGTM-06012 Test Paper and Paperboard Meter/paper Folding Endurance Testing Instrument
Brand: jinguang texter machine
SKU: 108256127

JGTM-06012 Test Paper and Paperboard Meter/paper Folding Endurance Testing Instrument thumbnail-1

JGTM-06012 Test Paper and Paperboard Meter/paper Folding Endurance Testing Instrument photo-1

US$ 2,000 - 5,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

jinguang texter machine

Model Number:

JGTM-06012

Contact Supplier Request Quote Chat Now

Cangzhou Kingsun Imp.& Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name jinguang texter machine

Model Number JGTM-06012

Power Electronic

Usage Paper Testing Instrument

JGTM-06012 test paper and paperboard meter/paper folding endurance testing Instrument

Specimen	15×150mm
Load method	hang load type
Folding speed	175±25CPM(or appointed speed)
Bending angle	+135°~ -135°
Counter	LCD,0~999,999
Volume	50×30×51cm
Weight	37kg
Power	1phase,AC220V,2.6A

l Introduction

PN- NZ135 MIT Type Paper Folding Endurance Tester is a new type testing apparatus to test Paper’s Folding Endurance, which is designed to be in accordance with related national standard GB/T 2679.5-1995, Paper and board-Determination of folding endurance (MIT tester). PN-NZ135 MIT Type Paper Folding Endurance Tester has various functions, such as, parameter testing, parametric transformation, parameter regulation, parameter display, parameter memory and parameter print. The tester has data processing function which can directly output result of statistical data with convenient operation, easy regulation and stable performance. The main functions are shown as following: compact structure, light weight, abundant functions, horizontal type and stable performance, so the tester is suitable for different paper and boards.

The number of double folding can be real-timely displayed on the tester, then press Folding times/ Logarithm button to display relevant Logarithm value and press Stat. to display standard deviation and variation coefficient. Press print button to print Statistical report on paper.

l Main Technical Specifications

1. Measuring Range: 0 ~ 99999
2. Folding Angle: 13520 Folding Frequency: 17510 times/min.
3. Folding Head Width: 91mm, Folding Radius: 0.380.02mm.
4. The spring tension: 4.91N~14.72N, when every 9.81N tension is added, the compression of spring is 17 mm reduced at least.
5. The clearances between folding ports are 0.25, 0.50, 0.75 and 1.00mm (four ranges).
6. The tension change due to the eccentric rotating of clamping folding head should not be larger than 0.343N.

Packaging & Shipping

1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.

2. Machine' Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.

1)24h online, if you have any question, we can help you solve it quickly (include pre-sales and after sales)
2)our testing equipments warranty for one year, after warranty, we can supply you longlife maintenance.
3)all things are in english. from technology consulting, purchasing and after service,we all have prefessional person to support.
