Paper Board Four Point Bending Stiffness Testing machine
Paper Board Four Point Bending Stiffness Testing machine
Model |
GT-N02B |
Plate Size |
500 mm x 500 mm or 600 mm x 600 mm 800 mm x 800 mm or 1000 mm x 1000 mm 1200 mm x 1200 mm or 1500 mm x 1500 mm |
MAX stroke |
500mm or 600 mm 800mm or 1000 mm 1200mm or 1500mm |
Measuring range |
0-10KN, 20KN, 30KN, 50KN. 70KN, 100KN ( Option) |
Indication error |
+/-0.5% |
Test Speed |
0.001-500mm/min, can set by computer, with up & down fast adjustment button of grips |
Force Unit Switch |
Kgf, N, Ibf, g, ton, Mpa |
Display |
Computer display mode |
Stop Mode |
Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function |
Machine Drive |
Servo motor drive, synchronous wheel and precision ball screw drive |
Power |
AC 220V 5A 50HZ |
Standards |
ISO2872, ISO2874, ASTM D642 |
INTRODUCTION :Good quality Full-auto smoothness tester ISO 5627 test smoothness of paper and board
PN-CT50KB Type Compression Testing Machine with multi-function and high precision is designed to test the compressive strength of standard size corrugated box, or packages and containers made of other material with a compressive strength smaller than 30kN.
With advanced mechanical structure of a pair of threaded shafts &guide pillars and imported motor for control, the testing machine has the following salient features: good parallelism, reliable measure precision and high return speed
(250mm/min.)
The testing machine is capable of various functions for all parameters in standards, Such as parametric test, display, memory, statistics and print function; data processing function
to gain the statistical result of all parameters directly; and automatic reset and fault diagnosis function and easy operation.
APPLICATIONS
Corrugated board boxes and Cartons, Plastic Packaging, Wooden box
STANDARDS
Meets ISO2872,ISO2874,GB/T4857.3,GB/T4857.4
FEATURES
1,Strength test
Strength test which belongs to a destructive test is mainly used to measure the deformation when the sample is loaded with maximum pressure or crushing strength.
