Waste Lubricant Oil Purification Machine ZJC12KY
(Suitable for lubricating oil with Kinetic viscosity < 220mm²/s)
Machinery oil, hydraulic oil, compressor oil, refrigerator oil and other industrial oil will be polluted by water, emulsification and particles from transportation and lubricating system running.
Features of the oils: high viscosity, high water content, high requirements on cleanness.
Waste Lubricant Oil Purification Machine ZJC12KY can effectively remove water and particles. To solve emulsification and remove water by vacuum distillation, remove particles by multi-stage of filters.
The special design and mature technology can promise its after-treatment oil index:
Water content: ≤50ppm
Filtration accuracy: 3 micron
Particles: no (by visual test)
Waste Lubricant Oil Purification Machine ZJC12KY
Item |
Parameter |
Unit |
ZJC0.6KY-R |
ZJC1.2KY-R |
ZJC1.8KY-R |
ZJC3KY-R |
ZJC6KY-R |
ZJC9KY-R |
ZJC12KY-R |
ZJC18KY-R |
|
Technical Parameter |
Flow Rate |
L/min |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
|
Working Vacuity |
Mpa |
-0.07 ~ -0.101 |
|||||||||
Working Pressure |
Mpa |
≤0.6 |
|||||||||
Temperature Range |
oC |
45-65 |
|||||||||
Power Supply |
|
50Hz 380V 3-Phase 4-Wire (or as requested) |
|||||||||
Total Power |
KW |
6+1.5 |
9+1.5 |
12+1.5 |
30+3 |
2X30+4.4 |
3X30+6 |
4X30+7 |
5X30+9 |
||
Inlet/Outlet Diameter |
mm |
20/20 |
20/20 |
25/20 |
32/25 |
38/32 |
64/48 |
76/64 |
89/76 |
||
|
Size |
Length |
mm |
1300 |
1300 |
1300 |
1900 |
1900 |
2100 |
2200 |
2300 |
|
Width |
mm |
1000 |
1050 |
1050 |
1400 |
1400 |
1500 |
1600 |
1700 |
||
Height |
mm |
1250 |
1450 |
1450 |
1950 |
2100 |
2150 |
2250 |
2300 |
||
Weight |
Kg |
350 |
420 |
510 |
950 |
1200 |
1600 |
2200 |
3500 |
||
Oil Treatment Index |
Water Content |
ppm |
≤100 |
||||||||
Filtering Accuracy |
µm |
≤5 |
|||||||||
Cleanness |
NAS |
Grade 5~7 |
|||||||||
Factory & workshop look
Oil before and after treatment
To be shipped
Exibition
Yuneng products list:
1. Insulation Oil filter machine machine:
ZJA Ultra-high Transformer / Insulation Oil filter machine machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil filter machine machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil filter machine machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) online Oil filter machine machine
Quantitative oil injection machine (customized product)
2. Turbine Oil filter machine machine:
JT coalescing dehydration oil filter machine machine (dehydration by special filters)
DYJC online turbine oil filter machine machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil filter machine machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil purifier machine machine:
ZJC-R Used lube oil purifier (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil filter machine machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil filter machine machine:
KYJ fire-resistance oil filter machine machine (EHC oil)
LY plate-frame pressure oil filter machine machine (simple, paper filtration)
YL mobile oil filter machine machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil filter machine machine (by chemicals)
YNZSY-LTY used tire oil filter machine machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
