Specifications
Portable Type Oil Filter Machine & Oil Filling Machine1 Replacement for pressurised filter machine
2 Particle removal
YL Portable Type High Precision Oil Filter Machine & Oil Filling Machine
(Small, Simple, Cheap)
Feature:
This portable oil filter machine is suitable to filter various impurities in insulating oil, turbine oil, mechanical oil, hydraulic oil 1-5 or more multi-stage filtration acceptable, filters can be wash / clean to reuse.
Filters choice diversified according to your oil and usage.
It is replacement for the frame-pressurized oil filter machine. It is simple in structure and easy to operate with low price.
For high-quality oil filter machine as vacuum oil filtration machine, please search our ZJA, ZJB, JZ, ZJC, JT, DYJC, KYJ… We have full series from low to high for your choice.
Parameter |
Type Unit |
YL-50 |
YL-80 |
YL-100 |
YL-150 |
YL-200 |
Flow Rate |
L/min |
50 |
80 |
100 |
150 |
200 |
Motor Power |
KW |
1.1 |
1.5 |
2.2 |
3 |
4.4 |
Inlet/Outlet Diameter |
mm |
32/25 |
38/32 |
44/38 |
48/44 |
64/48 |
Weight |
Kg |
100 |
120 |
150 |
200 |
260 |
Working Pressure |
Mpa |
≤0.5Mpa |
||||
Power Supply |
|
50Hz380V 3-Phase 4-Wire (or as requested) |
||||
Filtering accuracy |
µm |
≤5 |
||||
Delivery lift |
m |
≥15 |
||||
Factory & workshop look
To be shipped
Exhibition
Contact us to get best solution for your oils
Yuneng products list:
1. Insulation Oil filter machine:
ZJA Ultra-high Transformer / Insulation Oil filter machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil filter machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil filter machine (≤110KV) (one stage vacuum)
ZJ Vacuum Pumping machine (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).
JZ OLTC (on-load tap changer) online Oil filter machine
Quantitative oil injection machine (customized product)
2. Turbine Oil filter machine:
JT coalescing dehydration oil filter machine (dehydration by special filters)
DYJC online turbine oil filter machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil filter machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil filter machine:
ZJC-R vacuum Oil filter machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil filter machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil filter machine:
KYJ fire-resistance oil filter machine (EHC oil)
LY plate-frame pressure oil filter machine (simple, paper filtration)
YL mobile oil filter machine (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil filter machine (by chemicals)
YNZSY-LTY used tire oil filter machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
