Vacuum Fire-Resistant Oil Re-refining Equipment/EH Oil Purifier With CE

Vacuum Fire-Resistant Oil Re-refining Equipment/EH Oil Purifier with CE

Vacuum Fire-Resistant Oil Re-refining Machine/EH Oil Purifier is especially designed for fire-resistant oil with suitable material for vacuum dehydration, particles-removal and acid-reduction.

For customer choice, we also have a simple type to purify fire-resistant oil: KYJ-I high precision oil filtration. It has simple structure with multi-stage filters to remove particles to NAS grade 5. This machine almost could not remove water. It is suitable for customer who cares about cleanness but does not care about water content.

Features:

1. The tank and pipelines where fire-resistant oil going through are all made of stainless steel.

2. Dehydrate by vacuum distillation, water content less than 100ppm.

3. Oil-input and oil-output keep balance by photoelectric switch which is sensitive and accurate to monitor oil level in the tank, stop inputting oil when level marked high and keep inputting oil when low. Therefore, all series of YUNENG brand oil filtration machines never spray oil.

4. We use filters which designed only for fire-resistant oil to remove particles. Cleanness up to NAS grade 5.

5. There is system with absorbent to solve acid problem.

6. After treatment, the important index-resistivity up to ≥ 6 x 10⁹.

6. Good appearance, compact structure and easy operation.

Factory & workshop look

Machine Test

Parameter

Yuneng products list:

1. Insulation Oil purification machine:

ZJA Ultra-high Transformer / Insulation Oil purification machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)

ZJA High-vacuum Transformer / Insulation Oil purification machine (110KV-500KV project)) (2 stage vacuum)

ZJB Transformer / Insulation Oil purification machine (≤110KV) (one stage vacuum)

ZJ Vacuum Pumping machine (extract vacuum, dry transformer)

GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).

JZ OLTC (on-load tap changer) online Oil purification machine

Quantitative oil injection machine (customized product)

2. Turbine Oil purification machine:

JT coalescing dehydration oil purification machine (dehydration by special filters)

DYJC online turbine oil purification machine (dehydration by special filters and vacuum system)

ZJC-T vacuum oil purification machine for turbine oil (dehydration by vacuum system)

3. Lubricating Oil purification machine:

ZJC-R vacuum Oil purification machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)

ZJC-M Oil purification machine for OCS. (oil with high viscosity 22-320cst at 40°C)

4. Other kinds of oil purification machine:

KYJ fire-resistance oil purification machine (EHC oil)

LY plate-frame pressure oil purification machine (simple, paper filtration)

YL mobile oil purification machine (simple, cheap)

5. Waste oil regeneration machine (by chemicals or by high temperature distillation)

YNZSY used oil recycling machine (by chemicals)

YNZSY-LTY used tire oil recycling machine (by chemicals)

Waste oil distillation machine

6. Oil tester/ analyzer:

Dielectric oil breakdown strength tester

Water content tester

Inline Digital Flow Meter and Totalizer

Viscosity analyzer

Flash point analyzer (close cup)

Flash point analyzer (open cup)

Interfacial tension analyzer

Gas chromatograph
