Home > Industrial Equipment & Components > Filtration Equipment & Parts > Machine Oil Purifier > 2015 Famous Product for GF Dry Air Generator Used for Transformer

2015 Famous Product for GF Dry Air Generator Used for Transformer

2015 Famous Product for GF Dry Air Generator Used for Transformer thumbnail-1
2015 Famous Product for GF Dry Air Generator Used for Transformer photo-1
US$ 10,000 - 500,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Flow:
200M³/h
Working Pressure:
0.6-0.8Mpa
Contact Supplier Request Quote Chat Now
Chongqing Yuneng Oil-Filter Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Flow 200M³/h
Working Pressure 0.6-0.8Mpa
Place of Origin Chongqing, China
Brand Name Yuneng
Model Number GF-200
Usage Other, Dry Air Generator
Voltage 380v,50Hz,3 Phase or follow yours
Power(W) 25kw
Dimension(L*W*H) 230x170x235cm
Weight 1600kg
Certification CE, ISO9001
After-sales Service Provided Engineers available to service machinery overseas

                                                     2015 Famous Product for GF Dry Air Generator used for Transformer



                                                                                     (For transformer maintenance)





This 2015 Famous Product for GF Dry Air Generator used for Transformer is suitable for supplying dry air for transformer maintenance. Dry air can keep good insulation of transformer, reactor and other power facilities. Meanwhile, operators will not be short of oxygen to maintain inside.







It is safer, cheaper, more reliable & convenient than using nitrogen.



With GF Dry Air Generator, you can save time for maintenance and get good efficiency.







Parameter of 2015 Famous Product for GF Dry Air Generator used for Transformer



Item

 Parameter

Unit

 GF-50

 GF-100

 GF-150

 GF-200

 Technical Parameter

Flow

M³/h

50

100

150

200

Working Pressure

Mpa

0.6~0.8

Pressure Drop

Mpa

0.05

Noise

dB(A)

≤70

Working Power

KW

380V-50Hz   3 Phase 4 Wire

Total Power

KW

12

19

22

26





Size

Length

cm

215

215

230

230

Width

cm

155

155

165

165

Height

cm

230

230

230

230

Diameter

DN

32

40

50

50

Weight

Kg

900

980

1030

1050

After Treatment Index

Discharge Pressure

Mpa

0.02~0.03

Dew Point

°C

-50°C ~ -70°C

Particle

um

0.01

Oil content in air outlet

ppm

0.01





 Factory & workshop look



2015 Famous Product for GF Dry Air Generator used for Transformer2015 Famous Product for GF Dry Air Generator used for Transformer



More GF dry air generator



2015 Famous Product for GF Dry Air Generator used for Transformer2015 Famous Product for GF Dry Air Generator used for Transformer



Exhibition



2015 Famous Product for GF Dry Air Generator used for Transformer2015 Famous Product for GF Dry Air Generator used for Transformer







Contact us now for further discussion







Yuneng products list:





1. Insulation Oil Filtration:



ZJA Ultra-high Transformer / Insulation Oil Filtration Machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)



ZJA High-vacuum Transformer / Insulation Oil Filtration Machine (110KV-500KV project)) (2 stage vacuum)



ZJB Transformer / Insulation Oil Filtration Machine (≤110KV) (one stage vacuum)



ZJ Vacuum Pumping machine (extract vacuum, dry transformer)



2015 Famous Product for GF Dry Air Generator used for Transformer (produce dry air for operators to maintain transformer, reactors…).



JZ OLTC (on-load tap changer) online Oil Filtration Machine



Quantitative oil injection machine (customized product)



2. Turbine Oil Filtration machine:



JT coalescing dehydration oil filtration machine (dehydration by special filters)



DYJC online turbine oil filtration machine (dehydration by special filters and vacuum system)



ZJC-T vacuum oil filtration machine for turbine oil (dehydration by vacuum system)



3. Lubricating Oil Filtration machine:



ZJC-R vacuum Oil Filtration machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)



ZJC-M Oil Filtration machine for OCS. (oil with high viscosity 22-320cst at 40°C)



4.Other kinds of oil filtration machine:



KYJ fire-resistance oil filtration machine (EHC oil)



LY plate-frame pressure oil filtration machine (simple, paper filtration)



YL mobile oil filtration machine (simple, cheap)



5. Waste oil regeneration machine (by chemicals or by high temperature distillation)



YNZSY used oil recycling machine (by chemicals)



YNZSY-LTY used tire oil recycling machine (by chemicals)



Waste oil distillation machine



 6.Oil tester/ analyzer:



Dielectric oil breakdown strength tester



Water content tester



Inline Digital Flow Meter and Totalizer



Viscosity analyzer



Flash point analyzer (close cup)



Flash point analyzer (open cup)



Interfacial tension analyzer
