Specifications
1. Flexible rubber magnet material, passed RoHS for SGS test on rubber magnet, green production for European market;
2. Width: max. 1000(generally, 620mm, 630mm);
3. Thickness: from 0.25mm-10mm (generally, 0.3mm-8mm);
4. Length: as long as customers require (generally, 10m, 30m. 60m, 100m, 300m etc.);
5. High Magnetization Technique: steady pole gap 2mm.
6. can be covered with pvc of different color, adhesive, or inprinted arts paper.
Composition:
Ferrite Powder,
Macromolecule Compound (CPE, Nylon etc.)
Magnetization
•one-side. bipolar
•one-side. multipole
Surface Treatment:
Laminated with PVC Sheet
Laminated with Self-adhesive
•Chinese excellent standard self-adhesive
•USA 3M adhesive
Screen Printing
Application Examples:
•Professional Gifts
•Magnetic Photo Frame
•Car Decoration
•Magnetic Stationery
•Name Card
| Magnet Characteristics | BR | Hcb | Hcj | (BH)max | Density | ||||
| WINCHOICE GRADE | mT | Gs | kA/m | Oe | kA/m | Oe | kJ/m³ | MGOe | g/cm³ |
| YN10 | >230 | >2300 | >159 | >2000 | >207 | >2600 | 7.5-9.5 | 0.94-1.12 | 3.5-3.8 |
| YN12 | >245 | >2300 | >169 | >2120 | >247 | >3100 | 9.5-11.5 | 1.12-1.44 | 3.5-3.8 |
| YN14 | >265 | >2650 | >191 | >2400 | >263 | >3300 | 11.5-13.5 | 1.44-1.7 | 3.5-3.8 |
| YN16 | >275 | >2750 | >175 | >2250 | >263 | >3300 | 12.5-14.0 | 1.6-1.8 | 3.7-3.8 |
| YN20 | >280 | >2800 | >199 | >2500 | >358 | >4500 | 16-22.4 | 2.0-2.8 | 3.7-5.0 |
| YN25 | >350 | >3500 | >239 | >3000 | >478 | >6000 | 22.4-28 | 2.8-3.5 | 3.4-5.0 |
| YN35 | >400 | >4000 | >263 | >3300 | >557 | >7000 | 28-36 | 3.5-4.5 | 3.7-5.0 |
| YN40 | >460 | >4600 | >294 | >3700 | >637 | >8000 | 36-42.4 | 4.5-5.3 | 3.7-5.0 |
| YN45 | >500 | >5000 | >311 | >3900 | >677 | >8500 | 42.4-49.6 | 5.3-6.2 | 3.7-5.0 |
