Specifications
Color coated sheet coilThickness: 0.12mm-1.0mm
Wide: 500-1250mm
Zinc coating: Z40-150gms/
Inner diameter: 508mm / 610mm
Color coated sheet coil
high strength, strong firmness, good rain resistance.
PPGI PPGL
Thickness: 0.13mm-1.0mm
Wide: 500-1250mm
RAL: 1014 / 3003 / 3005 / 3011 / 5002 / 5005 / 6005 / 7004 / 8017 / 9002 / 9003 / 1014 / 6005
Zinc coating: Z40-150Gms/
Inner diameter: 508mm / 610mm
Surface Treatment: Coated
Certification: ISO 9001
Weight of coil :3-8 MT
Package Method : Vertical, Horizontal
Painting Thickness : 25 Microns on top side, 7 Microns on back side
Paint: Polyester; according to customer’s samples or RAL color catalog
Application: general using for roof, corrugated roof making, out side of buildings, structure, tile row plate, deep drawing, etc
Out company coated sheet PPGI is of high strength, strong firmness, good rain resistance, consistent rolling, good corrosion resistance, low time cost, and it is easy and convenient to install and dismantle. It is used widely in architecture, such as modern yard design, large industrial workshop, modern large airport, large gymnasium, and prefabricating heat insulation sandwich panel, etc. with the development of light industry, transportation, and shipbuilding , the application of color coated sheet develops from building material to automobile manufacturing, inner decoration of ships, household electrical appliance, furniture, container, and cooker, etc. and it is the new substitute of sprayed steel sheet.
Application in building industry:
|
First- stage Operation item |
Building Industry |
Outdoor Application |
Roof, structural terrace, panel, window, window frame , gate, garage door, roller shutter, booth, window shade, cabana, street waiting room, and cold store, etc. |
|
Indoor Application |
Door, partition, door frame, light steel structure piece of house, sliding door, folding screen, ceiling, washroom, ante hall of internal elevator, ventilation stack of stair, and communication pipeline, etc. |
End product quality testing standard:
Item |
Standard |
Polyester |
Thickness of coating film (um) |
GB/T 13448 |
≥ 20 um |
Luster of coating film 60°(%) |
GB / 49 (ASTMD523) |
70 40 – 70 40 High Middle Low >70 40-70 <40 |
Flexibility of coating film |
|
|
Rigidity of lead pencil |
GB/T 13448-92 (ASTMD3) |
≥F |
Impact |
GB/T 13448-92 |
≥9 |
T bending (d=) 80 |
GB/T 13448-92 (NCCA - 19)II |
Grade B≤3T Grade A ≤5T 90° |
Salt mist resistance (h) |
|
≥500 |
Category:
Variety |
Thickness |
Width |
Polyester |
Color coated sheet |
0.2 – 1.2 mm |
900 – 1300 mm |
Blue, red and white are available |
Category of material |
Standard |
Usage |
|
Color soated sheet |
JISG3312 |
Building, household electrical appliance, and transportation etc. |
|
