Specifications
plastic pipe production line1.single screw extruder
2.pipe diammeter range:16mm to 800mm
3.PLC control system
4.CE
plastic pipe production line :
Detailed Product Description
1.single screw extruder, very suitable to process PE resin with high capacity, max capacity 1000kg/h
2.The production line adopts reasonable design, absorbing safe producing technology, acquiring CE certificate.
3.Diameter range is 16mm-800mm, which can be changed into inch standard to meet clients special requirement.
Technical data:
Pipe range |
16-63mm |
20-110mm |
75-160mm |
90-250mm |
110-315mm |
160-450mm |
315-630mm |
500-800mm |
Extruder |
¢45mm |
¢60mm |
¢75mm |
¢75mm |
¢90mm |
¢90mm |
¢120mm |
¢150mm |
Extruder power |
AC30kw |
DC75kw |
DC110kw |
DC110kw |
DC160kw |
DC160kw |
DC280kw |
DC335kw |
Extrusion capacity |
60-100kg |
100-150kg |
250-300kg |
250-300kg |
350-400kg |
350-400kg |
650-700kg |
850-900kg |
Max. Production speed |
10m/min |
6m/min |
6 m/min |
6 m/min |
3 m/min |
1.2m/min |
0.9m/min |
0.7m/min |
PE pipe production line
System configuration
1 |
Vacuum loader |
1 set |
2 |
Hopper dryer |
1 set |
3 |
Single-Screw Extruder type SJ90/33 |
1 set |
4 |
Set of extrusion die head with all die cores , die cups and calibrators for pipes |
Whole 1 set |
5 |
C0-extruder |
1 set |
6 |
Vacuum calibration tank |
2 sets |
7 |
Extended cooling tank |
2 sets |
8 |
Four-claws Hauling Machine |
1 set |
9 |
Pipe Planet-Cutting Machine |
1 set |
10 |
Pipe stacker |
1 set |
detailed pictures :
calibrators :
CE :
About us :
Looking forward to your inquiry !
