Off line 220V mini ups with battery backup (Cute plug 400/600VA)
Feature and benefits:
Ease-of-use:
The plug-and-play function of the Q+allows you to start backing up your equipment the moment you take the unit out of the box (Q+400&600 only).Gain automatic integration with Windows,Mac and Linux with a simple connection to a USB port.
EcoControl:
The Q+manages your energy efficiency for you with EcoControl Master/Control outlets.When te items using the Control outlets(e.g.printer,scanner,fax) are automatically powered down- rewarding you with up to 30% in energy saving a typical battery backup.
Modern design:
The cute design of the Q+allows you to display it alongside your high-tech equipment for a sophiscated look. This unit can also be wall or desk-mounted for additional space saving.
Premium protection
The high-efficiency design of the Q+provides premium power protection for up to devices,including those using data lines.
Specification
| MODEL | Q+ 400 | Q+ 600 | ||
| CAPACITY | VA/W | 400 VA / 200W | 600VA / 300W | |
| INPUT | Phase | Single | ||
| Voltage | 120 VAC or 220/230/240VAC | |||
| Voltage Range | 90~145 VAC or 170/270 VAC | |||
| Frequency | 50/60 Hz | |||
| Frequency Range | 45~55Hz / 55~65Hz | |||
| OUTPUT | Phase | Single | ||
| (Inverter Mode) | Voltage | 120 VAC or 220/230/240VAC | ||
| Voltage Regulation | +/- 10% | |||
| (Batt. Mode) | ||||
| Frequency | 50Hz or 60Hz | |||
| Frequency Redulation (Batt. Mode) | +/- 1Hz | |||
| Output Waveform | Modified Sinewave | |||
| (Batt. Mode) | ||||
| POWER | P.F. | 0.5 | 0.5 | |
| FACTOR | ||||
| TRANSFER TIME | Typical | 2-6ms | ||
| BATTERY | Battery Type and number | 12V4.5Ah x 1pc | 12V7Ah x 1pc | |
| Recharging Time | 8 hours up to 90% | |||
| Backup Time (at a PC load with 15" monitor) | 10 minutes | 20 minutes | ||
| INDICATOR | AC Mode | Green LED lighting | ||
| Battery Mode | Yellow LED flashing every seconds | |||
| Low Battery at Battery Mode | Yellow LED flashing evevy seconds | |||
| Fault | Red LED Lighting | |||
| AUDIBLE ALARM | Battery Mode | Sounding Every 5 Seconds | ||
| Low Battery at Battery Mode | Sounding Every Second | |||
| Overload | Sounding Every 0.5 Second | |||
| Fault | Continuously Sounding | |||
| PROTECTION | Full Protection | Overload, Overcharge, Short Circuit Protection | ||
| RJ 11 Modem/Telephone Protection (Two Wires Single Line) | ||||
| PHYSICAL | Dimension (DxWxH) | 288X125X89 (mm) | ||
| Net Weight | 3.4kgs | 4.2kgs | ||
| Outlets | NEMA type | 6 NEMA outlets (3 for surge protection, 3 for battery backup) | ||
| French type | 6 Shuko outlets (3 for surge protection, 3 for battery backup) | |||
| Shuko type | 6 Shuko outlets (3 for surge protection, 3 for battery backup) | |||
| ENVIRONMENT | Operation Environment | 0~40 Degrees Centigrade, 0~90% relative humidity(non-condensing) | ||
| Noise Level | Less than 45dB | |||
| INTERFACE | Smart RS-232 | Optional | ||
| USB Port Option | Optional | |||
Customer Feedback
Our R&D team have tested your UPS, they are satisfied with the performance of the sample. All the test results are complying with the specification. We are highly appreciated it. --- N. Raja (from Chennai, India)
We are quite impressive with the IGBT function of this UPS. We are now trying to apply this model on our telecommunication systems. --- Robert Alles (from Munich, Germany)
Order information
Trade term: FOB Shenzhen / Hongkong
Delivery time: 7-21 days after confirmed the order
Packaging Detail: Standard export carton or OEM package
Warranty
1 years since the date of purchase
Warranty term
1. Under the terms of this warranty, if failure occurs under normal usage within warranty period, Helior Technology will provide free maintenance based on the proof-documents.
2. If Failure or damage occurs due to incorrect operation, wire connection, or any other mis-opeartions, Helior Technology will provide pay maintenance on charge basis.
