WP-20 Tungsten Argon Arc welding torch head
WP-20 series products list
Rating:250A DC,175A AC ,Tungsten Diameter:0.5mm-3.2mm
A COLLET |
|
PART NO. |
NAME |
13N20 |
Collet Dia. 0.5mm |
13N21 |
Collet Dia. 1.0mm |
13N22 |
Collet Dia. 1.6mm |
13N22M |
Collet Dia. 2.0mm |
13N23 |
Collet Dia. 2.4mm |
13N24 |
Collet Dia. 3.2mm |
B COLLET BODY |
|
PART NO. |
NAME |
13N25 |
Collet Body Dia. 0.5mm |
13N26 |
Collet Body Dia. 1.0mm |
13N27 |
Collet Body Dia. 1.6mm |
13N27M |
Collet Body Dia. 2.0mm |
13N28 |
Collet Body Dia. 2.4mm |
13N29 |
Collet Body Dia. 3.2mm |
C STD. CERAMIC CUP |
|
PART NO. |
NAME |
13N08 |
Std. Ceramic Cup Dia. 6mm |
13N09 |
Std. Ceramic Cup Dia. 8mm |
13N10 |
Std. Ceramic Cup Dia. 10mm |
13N11 |
Std. Ceramic Cup Dia. 11mm |
13N12 |
Std. Ceramic Cup Dia. 13mm |
13N13 |
Std. Ceramic Cup Dia. 16mm |
D LONG CERAMIC CUP |
|
PART NO. |
NAME |
796F70 |
Long Ceramic Cup Dia. 5mm |
796F71 |
Long Ceramic Cup Dia. 6mm |
796F72 |
Long Ceramic Cup Dia. 8mm |
796F73 |
Long Ceramic Cup Dia. 10mm |
E X-LONG CERAMIC CUP |
|
PART NO. |
NAME |
796F74 |
X-Long Ceramic Cup Dia.5mm |
796F75 |
X-Long Ceramic Cup Dia.6mm |
796F76 |
X-Long Ceramic Cup Dia.8mm |
796F77 |
X-Long Ceramic Cup Dia.10mm |
F GAS LENS BODY |
|
PART NO. |
NAME |
45V41 |
Gas Lens Body Dia.0.5mm |
45V42 |
Gas Lens Body Dia.1.0mm |
45V43 |
Gas Lens Body Dia.1.6mm |
45V44 |
Gas Lens Body Dia.2.4mm |
45V45 |
Gas Lens Body Dia.3.2mm |
G GAS LENS CUP |
|
PART NO. |
NAME |
53N58 |
Gas Lens Cup Dia.6mm |
53N59 |
Gas Lens Cup Dia.8mm |
53N60 |
Gas Lens Cup Dia.10mm |
53N61 |
Gas Lens Cup Dia.11mm |
53N61-S |
Gas Lens Cup Dia.13mm |
H LGE COLLET |
|
PART NO. |
NAME |
13N22L |
Lge Collet 1.6mm |
I LGE GAS LENS BODY |
|
PART NO. |
NAME |
45V116S |
Lge Gas Lens Body Dia.1.6mm |
J LGE DIA GAS LENS CUP |
|
PART NO. |
NAME |
57N75 |
Lge Dia Gas Lens Cup 10mm |
57N74 |
Lge Dia Gas Lens Cup 13mm |
53N88 |
Lge Dia Gas Lens Cup 16mm |
53N87 |
Lge Dia Gas Lens Cup 19mm |
1. Binzel 15AK,24KD,25AK,36KD Air Cooling Torch ,501D,602D Water Cooling Welding Torches
2. Panasonic 180A,200A,350A,500A Welding Torch and accessories
Panasonic robot 200A, 350A, 500A Welding Torch and accessories
3. Otc 180A, 200A, 350A, 500A Welding Torch and accessories
4. PSF/ESAB 205A, 305A, 405A, 505A Welding Torch and accessories
5. Trafimet 15AK, 24KD, 25AK, 36KD Welding Torch and accessories
6. TBI 15AK, 24KD, 25AK, 36KD Welding Torch and accessories
7. Plasma Cutting P80, AG60, PT31, AG100, SG51, JG60, JG100, SG55 Welding Torch
8. Tig welding Torches: WP9/WP12/WP17/WP18/WP26/WP20/WP27 Air/Water Cooling Torch
9. Mig/Co2 Welding Parts: contact tip, tip holder, swan neck, welding nozzle, gas diffuser, welding liner, teflon liner, cable plug, euro connector, panasonic connector, otc connector, insulatr, feed roller, protective paste, wire feeder, wire feeder motor
10. Tig /Argon Welding & Cutting Parts: electrode tip & nozzle, welding collect, collect body, gas lens, ceramic nozzle, long cap, short cap
11. Mig/Mag wire feeder: Euro Wire feeder, Panasonic wire feeder, and accessories
