Qirui Brand Most Competitive Price CE Approved Hydraulic Lathe

Name: Qirui Brand Most Competitive Price CE Approved Hydraulic Lathe
Brand: QiRui
Availability: InStock

FOB Price

US$ 2,000 - 20,000 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Hydraulic	Place of Origin	Jiangsu, China
Brand Name	QiRui	Model Number	HP79Z HP79Z HP79ZK-40 HP79Z HP79ZK-4079ZK-40 HP79Z HP79ZK-40
Voltage	Customized	Power(W)	7.5 kw
Weight	as requirement	Dimension(LWH)	1800 * 2350 * 3200
Certification	CE ISO SGS BV	Warranty	24 months after delivery
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Qirui brand most competitive price CE approved hydraulic lathe

Product Description

Powder hydraulic lathe is suitable for various kinds of dry powder products,it is equipped with

floating shelf, it can realize the synchronous bidirectional pressing forming process.

The series hydraulic machine includes four column type (type HP79Z) and frame type (HP79ZK type),with independent

hydraulic and electric control system,centralized control buttons, can realize the constant pressure and constant process oftwo kinds of forming process, has the function of automatic pressure maintaining time delay and andreturn etc..

The hydraulic lathe has automatic powder, three heavy pressure, pull the release" process action program,

completely suitable for multi step, special structure, mechanical parts of the powder products. Products with fly height, demoulding position

and pressed product height using positioning mechanism, and is equipped with a mechanical transmission device is

convenient for the user to adjust, to ensure consistency of product performance and accuracy of repeat positioning.

The series hydraulic lathe with accessories for customers to choose :

Mobility Workbench
The hydraulic damping system
Screen safety protection device
Displacement sensing device,
Knock-out device
Quick die clamping mechanism
Rail lubricate device

Qirui brand most competitive price CE approved hydraulic lathe
Nominal Force	Max. Working Pressure	Max. Distance	Effective Area of Table		Total Motor Power
400 kn	25 Mpa	900 mm	500 *460 mm		7.5 kw
Slide-Stroke Paramter	Max. Pressure	400 kn	Up-center Piston Parmeter	Max. Drawing Force	30 kn
	Max. Return Force	180		Max. Return Force	10 kn
	Max. Stroke	350 mm		Max. Stroke	50 mm
	Fast Down Speed	200 mm/s	Down-center Piston Parmeter	Max. Drawing Force	30 kn
	Slow Down Speed	10-25 mm/s		Max. Return Force	10 kn
	Return Speed	100 mm/s		Max. Stroke	80 mm
Push-up Piston Parmeter	Max. Push-up Force	280 kn	Overall Dimensions	Left- Right	1800 mm
	Max. Drawing Force	180 kn		Front - Back	2350 mm
	Max. Stroke	150 mm		Hight Above Ground	3200 mm
	Push-up Speed	48 mm/s		Height Down Ground	0 mm
	Max. Return Force	75 mm/s	At Piston Parmeter	Max. Drawing Force	30 kn
Delive Goods Machine	Delive Area	100 * 100 mm		Max. Return Forc	19 kn
Delive Goods Machine	Stroke	200 mm		Max. Stroke	60 mm

Related Model

Product Image

Packing	Each Qirui brand most competitive price CE approved hydraulic lathe in one Carton, Pallet or In nude
	Detail accordance with the actual dimension.
Shipping	Time of Delivery	Within 20-90days after make deposit.
	Shipping Terms	Seaway or Airway.

Certifications

Company Information

FAQ

Why you choose us?

1.Combination of production and trade

2.Strong design team

3. Competitive price

4. Fast delivery time

5. Oversea after-sales service

About the price

1. Do you have a competitive price?
Of course, we have. Have a try, you will know it.

2. How can I get the discount?

The discount is up to your order quantity. Small order will have higher price.
Your rolling order can help you get a bigger discount.
Delivery time, material, length of warranty and the weather need inspections all will influence the price.

About the payment

NO.	Image	Terms	Details
1		Western Uinon	40% at Sight and The Balance Payable Before Shippment
2		T/T	40% at Sight and The Balance Payable Before Shippment
3		L/C	Full Persent of The Total Amount
4		Ali Express	Full Persent of The Total Amount

About the quality

1. How do you control the quality?Our factory has ten years experiences in hydraulic press manufacture. And all our workers are 10-20 years experiences in it. We check the finish machine one by one, make sure the quality is good. If you need, we can also provide the commodity inspections.

2. How can I do if I receive the bad quality goods?

Sending us the photos and apply for the after-sales. We can provide you the Oversea after-sales service.

About the MOQ

1. What is your MOQ?

To our old customers, there is no MOQ. 1PCS, 5PCS, 10PCS… IS OK.

If you are a professional purchaser or specialize in hydraulic press, we can do very small quantity for you. 1pcs or 5pcs.

We hope there will be a bigger one after that. Then there will not be MOQ to you.

About the delivery Time

1. Usually, it is 20-90 days. According to your quantity.

2. Your urgent order is acceptable, But the price will be litter higher than normal.

About our factory local In

1.Where is your company?

Our factory locates in Nantong near Shanghai.

2.How can we get there?

You can only arrive at shanghai and we can go there to pick up you to our company to make a visit.
