Help CenterHP59-100T Four-column Glass Reinforced Plastic Hydraulic Press Machinery
Related Products
-
HP59-200T Four-column Pressed Glass Reinforced Plastic Hot Hydraulic Press MachineNegotiableMOQ: 1 Set -
HP59-315T Four-column Glass Reinforced Plastic Hydraulic Press MachineryNegotiableMOQ: 1 Set
-
HP59-500T Four-column Straight-side Glass Reinforced Plastic Hot Hydraulic Press MachineNegotiableMOQ: 1 Set
-
Glass Reinfoorced Plastic Hydraulic Press Auto Glass Press Brick MachineNegotiableMOQ: 1 Set
-
Hydraulic Press Auto Glass Press Brick Machine With PLC ControlNegotiableMOQ: 1 Set
Fiberglass products hydraulic press is the main equipmentmoulded of thermosetting and thermoplastic materials products. It has rapidly toward mould, preloading exhaust, rolling and slow to take off, slowly open mould and quick return process, fully satisfy the BMC/SMC glass fiber reinforced plastic products, hot pressing molding of plastic products ; Aerospace, vehicle shipping, energy, petrochemical, building materials, style of electrical appliances and other industries of glass fiber reinforced plastic products production key equipment.
Machinery with independent power mechanism and electrical system, PLC control, which can realize the adjustment, manual and semi-automatic three works.Working pressure of machine, pressing speed, heating temperature and range can be adjusted according to the craft, can finish the constant pressure molding, constant-distance forming two kinds of process methods, and have confirmed calender and automatically return action.
This machine by the host, dynamic mechanism, electric control system and temperature control system of four major components, the fuselage forms four pillar type and frame type two kinds big.
Machines are equipped with multi-channel heart pumping hydraulic system, can according to the product manufacturing process at the same time or separately with the machine automatically coordinated action.
| HP59-100t Four column Glass Reinforced Plastic Hydraulic Press Machinary | |||||||
|
Nminal force |
1000kn |
Stroke-tavel speed |
Empty slide down |
100mm/s | Tavel speed |
Push-up speed |
5-20mm/s |
|
Return force |
200kn | 20mm/s | 80mm/s | ||||
|
Push-up force |
200kn | Low speed | 1-4mm/s |
Return speed |
150mm/s | ||
|
Return force |
100kn | 5+/-15mm/s |
Total motor power |
7.5kw | |||
|
ure of liquid |
25mpa | Return speed | 5-20mm/s | ||||
|
Max.stroke of slide |
600mm | 100mm/s | |||||
|
Max. stroke |
250mm |
Effective area of table |
Left-right | 720mm/s | |||
|
Max.distance surface of table |
900mm | Front-back | 580mm/s |
|
|||
| Packing | Carton, Pallet or In nude | |
| Detail accordance with the actual dimension. | ||
| Shipping | Time of Delivery | Within 20-90days after make deposit. |
| Shipping Terms | Seaway or Airway. |
|
Why you choose us?
1.Combination of production and trade
2.Strong design team
3. Competitive price
4. Fast delivery time
5. Oversea after-sales service
About the price
1. Do you have a competitive price?
Of course, we have. Have a try, you will know it.
2. How can I get the discount?
The discount is up to your order quantity. Small order will have higher price.
Your rolling order can help you get a bigger discount.
Delivery time, material, length of warranty and the weather need inspections all will influence the price.
About the payment
| NO. | Image | Terms | Details |
| 1 | |
Western Uinon | 40% at Sight and The Balance Payable Before Shippment |
| 2 |
|
T/T | |
| 3 | L/C | Full Persent of The Total Amount | |
| 4 | |
Ali Express |
About the MOQ
1. What is your MOQ?
To our old customers, there is no MOQ. 1PCS, 5PCS, 10PCS… IS OK.
If you are a professional purchaser or specialize in hydraulic press, we can do very small quantity for you. 1pcs or 5pcs.
We hope there will be a bigger one after that. Then there will not be MOQ to you.
About the delivery Time
1. Usually, it is 20-90 days. According to your quantity.
2. Your urgent order is acceptable, But the price will be litter higher than normal.
About our factory local In
1.Where is your company?
Our factory locates in Nantong near Shanghai.
2.How can we get there?
You can only arrive at shanghai and we can go there to pick up you to our company to make a visit.
If you are interested in our products or any questions,
Plz feel free to contact with me.
