This series hydraulic press is suitable for the shaft parts with profile correction technology of shaft sleeve parts being connected and veneer parts bending, shallow drawing molding process, in addition, also can undertake nonmetallic products and forming technology of powder products. The pressure and stroke of the press can be adjusted within a certain scope.
Machine is equipped with independent hydraulic and electric control system, adopts the centralized control buttons, which can realize constant pressure and constant distance , it has confirmed calender and automatically return, and other functions.
The pressure of the machine and stroke can be adjusted within the scope of certain and arbitrarily.
| Qirui new normal constant distance 7.5kw manual hydraulic presses | |||||
| Nominal Force | Slide-Stroke | Max. Distance Between Lower Surface | Table Dimensions |
Max. Working Hydraulic Pressure |
|
| of Slide and Surface of Table | |||||
| 630kn | 500mm | 800mm | 800 *650 mm | 25Mpa | |
| Moving-Down Slide Speed | Slide Return Speed | Depth of Throat | Overall Dimensions | Motor Power | Weight |
| 40 mm/s | 50 mm/s | 350 mm | 1600*1200*2000 mm | 7.5 kw | 5500kg |
recommend products
| Packing | Carton, Pallet or In nude | |
| Detail accordance with the actual dimension. | ||
| Shipping | Time of Delivery | Within 20-90days after make deposit. |
| Shipping Terms | Seaway or Airway. | |
Why you choose us?
1.Combination of production and trade
2.Strong design team
3. Competitive price
4. Fast delivery time
5. Oversea after-sales service
About the price
1. Do you have a competitive price?
Of course, we have. Have a try, you will know it.
2. How can I get the discount?
The discount is up to your order quantity. Small order will have higher price.
Your rolling order can help you get a bigger discount.
Delivery time, material, length of warranty and the weather need inspections all will influence the price.
About the payment
| NO. | Image | Terms | Details |
| 1 | |
Western Uinon | 40% at Sight and The Balance Payable Before Shippment |
| 2 |
|
T/T | |
| 3 | L/C | Full Persent of The Total Amount | |
| 4 | |
Ali Express |
About the MOQ
1. What is your MOQ?
To our old customers, there is no MOQ. 1PCS, 5PCS, 10PCS… IS OK.
If you are a professional purchaser or specialize in hydraulic press, we can do very small quantity for you. 1pcs or 5pcs.
We hope there will be a bigger one after that. Then there will not be MOQ to you.
About the delivery Time
1. Usually, it is 20-90 days. According to your quantity.
2. Your urgent order is acceptable, But the price will be litter higher than normal.
About our factory local In
1.Where is your company?
Our factory locates in Nantong near Shanghai.
2.How can we get there?
You can only arrive at shanghai and we can go there to pick up you to our company to make a visit.
If you are interested in our products or any questions,
Plz feel free to contact with me.
