Car inner decoration special hydraulic press is suitable for pressing technology of materials of plasticity, such as cutting, bending, flanging, tensile plate. Can also be engaged in plastic products and semi-solid foaming and forming technology of the piece of paper.
This equipment has the independent power mechanism and electrical system. And central control by PLC, by an electronic touch screen to realize the adjustment, manual and semi-automatic three kinds of operating mode.
This equipment working pressure, pressing speed, the traveling schedule scope may be adjusted according to the requirements of the process, and the constant-pressure to complete and constant-distance forming is forming two kinds of process methods. Constant-pressure molding process way to have after the suppression guarantees calender and automatically return action.
This equipment adopts the structure of three beam four column, operating space is capacious, it is convent to observe around and adjust the mould. the whole machine structure is simple. And increases the rapid downward, largely improve the efficiency of users.
The series hydraulic machine equipped with accessories for customers to choose :
• Mobility workbench
• Hydraulic damping system
• Screen safety protection device
• Displacement sensing device
• Knock-out device
• Quick die clamping mechanism
• Rail lubricate device
| Auto brake pads special hydraulic press with PLC control | |||||
| Nominal torce | Returm force | ure of liquid | Max.stroke of slide | Max.stroke of slide | Motor power |
| 1000kn | 125kn | 25Mpa | 1000mm | 1300mm | 7.5kw |
| Effective area of table |
Effective area of table |
||||
| Speed of fast down | Speed of fast down | return | Left right | Front back | |
| 80mm/s | 5-10mm/s | 100mm/s | 3500mm | 2000mm | |
| Distance between coiumns | Distance between coiumns | ||||
| Left right | Front back | Front back | Left right | Height above floor | |
| 3650mm | 1760mm | 2100mm | 5000mm | 4400mm | |
| Packing | Carton, Pallet or In nude | |
| Detail accordance with the actual dimension. | ||
| Shipping | Time of Delivery | Within 20-90days after make deposit. |
| Shipping Terms | Seaway or Airway. |
|
Why you choose us?
1.Combination of production and trade
2.Strong design team
3. Competitive price
4. Fast delivery time
5. Oversea after-sales service
About the price
1. Do you have a competitive price?
Of course, we have. Have a try, you will know it.
2. How can I get the discount?
The discount is up to your order quantity. Small order will have higher price.
Your rolling order can help you get a bigger discount.
Delivery time, material, length of warranty and the weather need inspections all will influence the price.
About the payment
| NO. | Image | Terms | Details |
| 1 | |
Western Uinon | 40% at Sight and The Balance Payable Before Shippment |
| 2 |
|
T/T | |
| 3 | L/C | Full Persent of The Total Amount | |
| 4 | |
Ali Express |
About the MOQ
1. What is your MOQ?
To our old customers, there is no MOQ. 1PCS, 5PCS, 10PCS… IS OK.
If you are a professional purchaser or specialize in hydraulic press, we can do very small quantity for you. 1pcs or 5pcs.
We hope there will be a bigger one after that. Then there will not be MOQ to you.
About the delivery Time
1. Usually, it is 20-90 days. According to your quantity.
2. Your urgent order is acceptable, But the price will be litter higher than normal.
About our factory local In
1.Where is your company?
Our factory locates in Nantong near Shanghai.
2.How can we get there?
You can only arrive at shanghai and we can go there to pick up you to our company to make a visit.
