Help CenterTPJ Pallet Press Machine
Related Products
-
RFM2 Serious Wood Pallet Making MachineUS$ 4,000 - 500,000MOQ: 1 Set -
BHBYJ Particle Board Hot Press MachineUS$ 14,516 - 500,000MOQ: 1 Set
-
Ceramic Filter Ring/Tablet/Block Hydraulic Forming MachineNegotiableMOQ: 1 Set
-
Mental Wire Scourer Forming Machine/Best Quality and High OutputUS$ 1,000 - 5,000MOQ: 1 Set
-
Mental Wire Scourer Forming Machine/New DesignUS$ 1,000 - 5,000MOQ: 1 Set
Specifications
The mould press pallet machine is one of our main products,which meets with environmental-friendly requirements.Pallet hot press machine
The mould press pallet machine is one of our main products,which meets with environmental-friendly requirements.Except the finished products' advantages of light,good integrity,no nails and throns,on-toxic,no-smell,non-rot,easy to clean ,no combustion,no spark,waterproof,anti-explosion and anti-skid,it makes many profit for the buyer because its maintenance-free ,multifunctional-purpose etc.It not only can be used for the mould pallet,but also used for the flat plate.The finished product is widely used in the storage and transportation of many industries such as food,tobacco,pharmaceutical,chemical,machinery ,electronic appliances,auto parts,beer and others,which is highly improving the work efficiency.
Main parameters
Model |
RFM2 |
Pressure |
600Ton 15Mpa |
Hydraulic oil cylinder diameter |
290mm |
Hydraulic oil cylinder quantity |
4 |
Feeding way |
Manual feeding |
Heating temperature |
130degree |
Motor |
5.5kw |
Pallet density |
850kg/cubic meter |
Pallet dimension |
1.2*1.2m 1.2*0.8m 1.2*1m 1.1*1.1m |
Pallet weight |
20kg 15kg 17kg 17kg |
Capacity |
144 piece per day |
Time for enough pressure |
35 seconds |
Time for one piece |
450seconds |
Weight |
9500kg |
Dimension |
2300*1300*4300mm |
More pictures for reference
The above pictures are the mould
The above pictures are the hydraulic cylinder
This above picture is the hot oil container
