Specifications
cotton fiber opening machine1.reliable performance, stable operation
2.easy operation, low loss
3.low noisy,environmental
cotton fiber opening machine
Product information:
Used to turn head cloth, cotton yarn waste, discarded clothing, cotton, chemical fiber, linen, leather, plastic film, paper, non-woven fabrics and other materials into cotton for re-usage and make the finished cotton clean.
Characteristics:
1. New rack structure is scientific, reasonable and safe, the performance is reliable; operation is stable, and easy to handle.
2. Output is high, good loosing and cleaning effects, low-loss, environmental and low noisy.
3. Adopt to oblique gear speed reducer make the good adaptability during the long time working, and will not be heat, has long life time.
4. Equipped with the new designed rack, loosing and recycling combined working models, gradually processing materials, reduce the damage to fiber, improve the length of fiber.
5. Special structure roller and arc-shaped cotton feeding board, and has long life time
6. Gap is easy to adjust and maintenance
7. Have thickened roller, four roller cotton feeding device, gear roller and other feeding type, is free to choose according to different materials.
Technical parameters:
Roller Quantity |
Model |
Dimensions(mm) |
Motor Power |
Length of rollers |
Diameter of rollers |
Weight |
Output |
One Roller |
QTJ250A |
2000X1700X1300 |
5.5kw |
1000 mm |
250mm |
800kg |
150kg-250kg |
Two Rollers |
QTJ250B |
2900X1700X1300 |
29kw |
1000 mm |
250mm |
1500kg |
150kg-250kg |
Three Rollers |
QTJ250C |
4000X1700X1300 |
34kw |
1000 mm |
250mm |
2350kg |
150kg-250kg |
Four Rollers |
QTJ250D |
5100X1700X1300 |
40kw |
1000 mm |
250mm |
3200kg |
150kg-250kg |
Five Rollers |
QTJ250E |
6200X1700X1300 |
45.5kw |
1000 mm |
250mm |
4050kg |
150kg-250kg |
More pictures:
