Specifications
Be used in various foundation projects suan as deep borehole cast pile,slurry reverse circulation diaphragm wall panel trenchIntroduction
CS100 slurry separator can be used in various foundation projects such as deep borehole cast pile, HDD drilling and slurry reverse circulation diaphragm wall panel trench, slurry trench, slurry wall.
Usage
CS100 slurry separator has some benefits as follows:
1. Mud Property of Bored or Punch Piles can be controlled
2. mud material can be reusable by sand and cutting particle removal from mud
3. mud circulation is closed in the jobsite to limit the water pollution
4. limit the solid waster material for transport
Main features:
1. Linear Vibrating Screen can be adjusted for different solid diameter
2. Max capacity 100m3/h, 80% above separating rate and -0.074~-0.045mm diameter grade
3. Electric motor and pump is tough and reliable
4. Pilot operated ball float valve can avoid pumping without mud
5. Newly designed hydro cyclone
6. Easy-mounted rubber Shock absorber makes low noise
7. Whole machine is modular designed for repair and transportation
8. Injection pipe line can prevent sand sinking to reduce water overflows
Pictures:
