EverExceed Phosphate lithium battery for PV application EP-4820
The battery pack is special optimized for PV application.
That means more service life and more reliability in solar energy store. This has prompted higher requirements for the temperature range are gradually or have been started seeking and studying the new battery solution. Based on its own technical features as high capacity, high voltage and free of pollution, the lithium ion battery is widely concerned by people with a rapid development stance. It will be the first choice for the high requirement energy store battery solution.
EverExceed solar LiFePO4 battery system is mainly used for the energy store battery of Photovoltaic system; its advance intelligent lithium battery management technology to ensure the intelligent automatic management. With “ Energy transfer “ balanced patented technology, EverExceed fe lithium provide high efficiency balanced and prolong system operate life.
- Increased energy in given space;
- Easy installation and up scaling;
- High operational reliability;
- Optimized supervision strategy through remote;
- Control/diagnostic;
- Very long life time;
- Preventive but not premature replacement at the end the life.
- High cycle life and deep cycle: For infrastructure powered from high cycle life and deep cycle cost primary energy sources (e.g. diesel generators powered in off-grid or unreliable grid locations and anywhere energy storage systems are used to reduce CO2 emissions).
- Battery management: The battery system adopts special BMS high performance battery management module which is featured with voltage, current and temperature protection and a preferable communication between the battery system and the host.
- Intelligent monitoring: The monitoring unit checks the charging and discharging current, voltage and monomer battery surface temperature and ambient temperature automatically.
- Lightweight, high energy density standby power: The EP-48xx series batteries, due to their excellent properties, are the optional energy storage solution where limited space and or weight are important factors.
- Excellent expansion capability: Configuration flexibility, support parallel connection expansion.
| Model | EP-4810 | EP-4820 | EP-4830 | EP-4840 | EP-4850 | EP-4860 | EP-48100 |
| Nominal characteristics | |||||||
| Battery type | Iron phosphate battery (LiFePO4) | ||||||
| Nominal voltage (V) | 48V | ||||||
| Nominal capacity (Ah) | 10 | 20 | 30 | 40 | 50 | 60 | 100 |
| Nominal energy (KWh) | 0.5 | 1 | 1.5 | 2 | 2.5 | 3 | 5 |
| Max. charge current (A) | 10 | 20 | 20 | 20 | 25 | 25 | 50 |
| Output voltage (V) | 40.5 to 54 | ||||||
| Max. output current (A) | 10 | 20 | 30 | 40 | 50 | 60 | 100 |
| Charging current limit (A) | 2 | 5 | 5 | 10 | 10 | 10 | 10 |
| BMS with equalization | Yes | ||||||
| Communication | RS485/CAN | ||||||
| Dimensions (W*D*H in mm) | 483*394*45 | 483*273*135 | 483*433*135 | 483*433*135 | 483*433*135 | 483*433*135 | 483*451*220 |
| Weight (kg) | 10 | 16 | 22 | 26 | 30 | 33 | 60 |
| Operating conditions | |||||||
| Cycle life (100% DOD; 20℃/68℉) | > 3000 cycles | ||||||
| Discharge temperature | 20℃ to + 60℃ | ||||||
| Charge temperature | 0℃ to + 60℃ | ||||||
| Storage temperature | 40℃ to + 65℃ | ||||||
| Parallel ability | Support parallel connection expansion | ||||||
| Note: 1) Nomianl voltage --- cell nominal voltage 3.2V, 48V battery consist of 15 cells. 2) Nominal capacity --- discharge with constant current (0.2CA) to end voltage (40.5V) at 20℃. | |||||||
Length 19 inches, 2U/3U rack-mount design M6 terminals on front panel.
The battery system informs the user and the application, via visual communication by LEDs on front panel and alarms (dry contacts). In option, the supervision can be done through CAN bus or RS485.
The data available are:
State of charge, state of health
Alarm level (minor, major); alarm reason
Operating condition (voltage, temperature, identification number).
EverExceed Group was established in 1980s and has its headquarter in Shenzhen, China, and subsidiaries in Singapore, UK and operations in six continents. We are manufacturing and supplying worldwide reliable power solutions with continuous innovative technologies, cost-effectiveness and good service, including industrial batteries (lead acid batteries, NiCad batteries, Lithium-ion batteries), solar power systems, UPS systems and DC power systems.
EverExceed attained the certificates of ISO9001 & ISO14001, and our products are accredited with TUV / VDE/ CE/ IEC/ UL/ RoHS/ DEKRA. Our advanced technology, professional technique, automatic equipment, experienced staff and strict operation system assure high level product quality. By now, reliable products with our brand “EverExceed” have been exported to more than 60 countries all over the world.
