SJS Series--Tighten Bearing Locking Nut
1. product description
Lock method is using the flexible of steel itself to axial locking, mandatory lock. This productespecially works for the condition of poor working, nut easy loose. Its lock capacity is more than 3times of traditional screw cap, thus its special advantages. SJS design way of locking; because of the assembly deviation it can not guarantee the plane and the deflection of the vertical of the thread, and thus its shortcomings.
Material: SCM440 (42 crm04) conditioning
hardness: HRC28 ° - 32 °
accuracy of thread: ISO 6 h precision turning
deflection of low plane: 0. 007 mm
2. lock nut structure
3. Product Specifications
Nut type | D | L | d | n-mxl | n | b | c | Nm |
SJS M 16×1.5 | 34 | 18 | 29 | 4-M4×12 | 4 | 4 | 24 | 3.5 |
SJS M 17×1 | 37 | 32 | 26 | |||||
SJS M 18×1.5 | 38 | 33 | 28 | |||||
SJS M 20×1 | 40 | 35 | 30 | |||||
SJS M 20×1.5 | ||||||||
SJS M 22×1.5 | 42 | 37 | 32 | |||||
SJS M 24×1.5 | 44 | 39 | 34 | |||||
SJS M 25×1.5 | 45 | 20 | 40 | 4-M4×14 | 5 | 35 | ||
SJS M 26×1.5 | ||||||||
SJS M 28×1.5 | 46 | 43 | 37 | |||||
SJS M 30×1.5 | 48 | 45 | 39 | |||||
SJS M 32×1.5 | 50 | 22 | 47 | 4-M4×16 | 41 | |||
SJS M 33×1.5 | ||||||||
SJS M 35×1.5 | 53 | 50 | 44 | |||||
SJS M 38×1.5 | 56 | 53 | 47 | |||||
SJS M 39×1.5 | ||||||||
SJS M 40×1.5 | 58 | 55 | 49 | |||||
SJS M 42×1.5 | 60 | 51 | ||||||
SJS M 45×1.5 | 68 | 63 | 6-M4×18 | 6 | 6 | 57 | ||
SJS M 48×1.5 | 69 | 25 | 65 | 58 | ||||
SJS M 50×1.5 | 70 | 66 | 60 | |||||
SJS M 52×1.5 | 72 | 68 | 62 | |||||
SJS M 55×1.5 | 75 | 71 | 65 | |||||
SJS M 55×2 | 4.5 | |||||||
SJS M 58×1.5 | 82 | 26 | 77 | 6-M5×20 | 70 | |||
SJS M 60×1.5 | 84 | 79 | 72 | |||||
SJS M 60×2 | ||||||||
SJS M 62×1.5 | 86 | 28 | 82 | 75 | ||||
SJS M 64×1.5 | ||||||||
SJS M 65×1.5 | 88 | 84 | 77 | |||||
SJS M 65×2 | ||||||||
SJS M 68×1.5 | 93 | 87 | 7 | 80 | ||||
SJS M 70×1.5 | 95 | 89 | 82 | |||||
SJS M 70×2 | ||||||||
SJS M 72×1.5 | 97 | 91 | 84 | |||||
SJS M 75×1.5 | 100 | 94 | 87 | |||||
SJS M 75×2 | ||||||||
SJS M 80×2 | 110 | 32 | 103 | 6-M6×22 | 8 | 95 | 8 | |
SJS M 85×2 | 115 | 108 | 100 | |||||
SJS M 90×2 | 120 | 113 | 105 | |||||
SJS M 95×2 | 125 | 118 | 110 | |||||
SJS M 100×2 | 130 | 123 | 115 | |||||
SJS M 105×2 | 135 | 128 | 120 | |||||
SJS M 110×2 | 140 | 133 | 125 |
4.packaging
