china manufacturing line c profile purlin galvanized steel stud and track roll forming machine
| | Huachen is factory which manufacture machine and also do export. |
We have exported over 70 countries, and familiar with your require. | |
Suitable to GI, PPGI, aluminum and Zinc coil. | |
Free 1 year gurantee, and life long service. |
1). The Main Parameter For galvanized steel stud machine
No. | main parameter of galvanized steel stud machine | |
1 | Suitable to process | Color steel plate |
2 | Width of the plate | 170mm |
3 | Roller | 14 rows |
4 | Dimensions | 4600*750*910mm |
5 | Power | 3+3kw |
6 | Thickness of the plate | 0.3-0.5mm |
7 | Productivity | 20m/min |
8 | Material of the cutting blade | Cr12 |
9 | Diameter of the roller | Φ66mm |
10 | Weight | About 3.5T |
11 | Voltage | 380V 50Hz 3phases |
14 | Control system | PLC control |
2). Check If galvanized steel stud machine Profile Suitable to You.
3). This is The Whole Line of galvanized steel stud machine
Manual Uncoiler—Galvanized Steel Stud Machine—Computer Control System—Hydraulic Control System—Form Cutter
4). Components and Technical Specification
1. Manual Uncoiler
Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading capacity:5T
Inner diameter: 500-508mm
2. Feeding Table
Put the raw material(steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.
3. Hydraulic System
Power:4kw,Hydraulic oil: 40#
hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.
4.Computer Control Cabinet
The target piece`s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use.
PLC:EURA
5.Cutting System:
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
Material of blades: Cr12,quenching treatment
6.Main Roll Forming Machine:
7.Output Table
Detail Pics:
Did Not Find What You Want? We Have More Here!
We have CE certification and ISO certification.
