Solar vacuum tube for solar heater
Solar vacuum tube working principle:
1. On heat-pipe collector, the condenser zone of the heat-pipe is inserted to the copper sleeves
which are distributed on the water pipe averagely.
2. After the solar energy is absorbed by the vacuum tubes, it is transferred to the heat-pipe
through the aluminum fin.
3. Heated by the energy, the medium in the heat-pipe is working and transferring the heat
energy to the condenser zone.
4. When water or other medium in the water pipe flows across the copper sleeves, they would
bring the energy and be heated.
5. The heated water or other medium makes water in the tank hotter and hotter by walking
across the coils in the tank.
Solar vacuum tube features
1. Higher heat efficiency: Advanced heat transferring style of the heat pipe, excellent selective
absorbent coating and perfect combination with high vacuum heat preservation
2. Wide applicable range: As the heat pipe has less heat capacity, it can be started quickly even
under cloudy fine day and collect heat effectively. It can work normally even -30 below degree.
As no water in the vacuum tube, it can effectively prevent lowing of heat efficiency due to frost
cracking or scaling
3. Each individual tube can work independently, and the whole machine can still work if
individual tube is damaged. The service life of the heat pipe can be longer than 15years.
4. The unique connection between the heat pipe and the vacuum tube can ensure both sealing
and replace of damaged glass vacuum tube.
size:
* 47mmx1500mm
* 47mmx1800mm
* 58mmx1800mm
| Packaging Details: | 1.Standard export wooden case for sample... 2.Standard export cartons for container with foaming.... |
|---|---|
| Delivery Detail: | Within 15 days |
