Home > Products > Integrative Pressurized Solar Water Heater > 2015 New Style Unpressurized Solar Hot Water Heater
2015 New Style Unpressurized Solar Hot Water Heater
- 400 Set / Sets per Month
- Shanghai Ningbo
- T/T Credit Card
Product Details
Type: | Evacuated Tube | Pressure: | Pressurized | Circulation Type: | Indirect / Closed Loop (Active) |
Heating System: | Thermosyphon (Passive) | Connection Type: | Other, Direct-Plug, Indirect-plug | Installation: | Freestanding |
Housing Material: | Other, Galvanized steel | Certification: | CE, Other, CE, CE, CCC,ISO,SGS, CE,ISO,CCC,SGS | Capacity: | 250, 250 |
Place of Origin: | Zhejiang, China | Brand Name: | SANNENG / OEM | Model Number: | IP6016 |
Product Description
2015 New Style Unpressurized Solar Hot Water Heater
Model: IP6016
The heat pipe is hollow and evacuated, as same as the solar tube.There are a small quantity of purified water and some special additives in it.The heat pipe used in Qirui solar collectors has a low boiling point.Thus, when it is heated, the water vaporizes rapidly.The vapor rises to the top of the heat pipe and transfers heat.As the heat is lost at the top, the vapor condenses to form a liquid (water) and returns to the bottom of the heat pipe once again to repeat the process.
Features
1. It can withstand pressure of tap water when it works.
2. There is no need to wait.
3. Completely automatic operation.
4. Drinking water quality to promote life quality.
5. Temperature preservation can last for 80hours.
6. Without volatile tubes.
7. Without incrusting, long usage life
Advantages
1). Highly efficient absorber of high performance with daily average efficiency over 50%;
2). Start up quickly, heat pipe transfer the heat energy into the storage tank in one direction.
3). Withstand pressure of 6 Bar, can be connected directly with city water.
4). No water inside the evacuated tubes; The solar water heater can still in service even with several tubes breakage;
5). Highly efficient insulation with polyurethane foam;
6). Simple structure, easy to assembly and install, diffuse flat plate reflector can be assembled easily with its module structure;
7). Can be used all year round in the cold climate;
8). Can be used together with Auxiliary electric boost;
9). Long service life, can be used as long as 15 years.
Specifications
1). Material of storage tank
2). Outer tank: Colorful steel, 0.4mm thick
3). Inner Tank: Crystal liner 4mm, steel 1.5 mm
4). Thick Insulation: Polyurethane foam, 50 mm
5). Working pressure: 6Bar
6). Daily efficiency: ≥ 55% (≥ 42% in winter)
7). Working temperature: 60 Degree Celsius -35 Degree Celsius
8). Vacuum tube specifications: 58mm*1800mm
9). Lifetime: 15 years
Product Model | Tubes Qty. | Tank (L) | Absorbing Area (m 2 ) | Weight (KGS) | Dimension (L×W×H) | Qty. per 20FT/40FT/40HQ |
IP470-1800/58-18 | 15 | 150L | 1.37 | 93 | 1830*1690*1600 | 35 / 70 / 85 |
IP470-1800/58-20 | 16 | 160L | 1.52 | 103 | 1830*1850*1600 | 32 / 64 / 78 |
IP470-1800/58-24 | 18 | 180L | 1.83 | 125 | 1830*2170*1600 | 27 / 55 / 67 |
IP470-1800/58-30 | 20 | 200L | 2.29 | 156 | 1830*2650*1600 | 23 / 46 / 55 |
IP500-1800/58-18 | 22 | 220L | 1.37 | 98 | 1830*1690*1630 | 34 / 69 / 83 |
IP500-1800/58-20 | 24 | 240L | 1.52 | 109 | 1830*1850*1630 | 31 / 63 / 76 |
IP500-1800/58-24 | 25 | 250L | 1.83 | 132 | 1830*2170*1630 | 26 / 54 / 65 |
IP500-1800/58-30 | 30 | 300L | 2.29 | 164 | 1830*2650*1630 | 22 / 45 / 53 |
1) Inner tank: 1.2mm food grade stainless steel304, Outer tank: 0.4mm color steel /stainless steel
2) Insulation: 50-55mm polyurethane,heat preservation 72hours/3days
3) Capacity: From 100L To 500L
4) Pressurized tank, working pressure 6 bar, Max resistance 12 bar.
5) Copper heat pipes for rapid heat transfer, No water through the tube, So it can good working in winter without freeze.
Remark
Delivery time: 7-15days
Payment term: T/T, L/C, Western Union
Warranty: 5 Years for the full system, 15 Years for the vacuum tube, and 1year for the accessories
Delivery term: FOB preferred, CFR and CIF acceptable
Certificates: CE,ISO,CCC,SGS
