Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg

Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg thumbnail-1
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg thumbnail-2
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg thumbnail-3
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg thumbnail-4
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg photo-1
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg photo-2
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg photo-3
Double Electric Magnetic Lock for Wooden Door, Fireproof Door, Holding Force: 180kg photo-4
US$ 30 - 35 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
PROYU
Model Number:
PY-EL6-1
Contact Supplier Request Quote Chat Now
Shenzhen Proyu Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name PROYU
Model Number PY-EL6-1

180kgs Security electric Double door magnetic lock for Acccess control system



Product Description





Product Parameter Parameter Description
Size 340Lx41.4Wx20.5H(mm)
Armature Plate Dimension 130Lx33Wx9.3H(mm)
Holding Force 180kgx2(350Lbsx2)
Input Voltage 12/24VDC+10%
Current Draw 300mAx2 at 12VDC       150mAx2 at 24VDC
Suitable Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp  -10~+55℃(14-131F)
Humidity  0~90%(non-condensing)
Cover Finish Anodized aluminum
Lock Finish Zinc
Armature Plate Finish Zinc
Weight 2.4KG



 Double electric magnetic lock for wooden door, fireproof door, Holding Force: 180kgDouble electric magnetic lock for wooden door, fireproof door, Holding Force: 180kg



 installation drawing:

Double electric magnetic lock for wooden door, fireproof door, Holding Force: 180kgDouble electric magnetic lock for wooden door, fireproof door, Holding Force: 180kg



Double electric magnetic lock for wooden door, fireproof door, Holding Force: 180kgDouble electric magnetic lock for wooden door, fireproof door, Holding Force: 180kg


Our Services





Advantage:

1.Good quality with competitive price

2.Professional technique supports and great services

3.Fast delivery and safe shipping way

Payment terms:

T/T,Western Union, Paypal

Shipping way

Fast way: by Express courier, such as DHL,FedEx,UPS,TNT,EMS etc.,

Feedback quickly:

Any inquires will be replied within 24 hours;

We can provide online supports for you when need helps on testing.

Warranty:

1-2 years warranty from the date of delivery.A lifetime technical support.

We warmly welcome you will join us,make Win-Win cooperation.
