Specifications
1.load capacity:0.1-10 ton2.the far-end control and multi-control points
3.safe,steady and long working life
4CE approved
brief introduction
The guid rail lift table is mainly used for the things up and down between the floors,it can be used for somewhere like stair hall, Stereo garage,underground garage and warehouse and so on.It can be installed indoor or outdoor.
It’s load capacity is 0.1-10ton
Advantages
Hydraulic lifting system,the far-end control and multi-control points at the different floors could be realized hierarchical control.Stop anywhere at the preconcerted and accurate location point.It can work under any condition,great load capacity,safe and reliable.There are sensitive over load protection devices looking device for failing protection.
Applications
Stationary lead rail lift provides fast,efficient,convenient and safe access to balconies,basements,and any levels in multistoried building.it can be installed indoor and outdoor applications.
Availabilities
Lifting height:1.65-20m; load:0.1-1T(customer-made)
12 months from delivery apart from artificial damage.
Free lifelong technical service.
Advantages
Safety
Hydraulic elevators not only have all safety device of the traditional elevator,but also have the special safety system hereinafter.
The lower operating cost
LRLseries |
Load |
Platform size |
Lifting height |
Non-work height |
Dimension(m) |
Pump station |
LRL3-2.4 |
3T |
2.0*2.0M |
2.4M |
660MM |
2.0*2.0*0.66 |
4KW|380V |
LRL2-5 |
2T |
2.1*1.2M |
5.0M |
870MM |
2.1*1.2*0.87 |
4KW|380V |
LRL1-4.5 |
1T |
2.1*1.5M |
4.5M |
800MM |
2.1*1.5*0.80 |
3KW|380V |
LRL5-6.5 |
5T |
2.2*1.6M |
6.5M |
1280MM |
2.2*1.6*1.28 |
5.5KW|380V |
LRL3-6.5 |
3T |
2.2*1.9M |
6.5M |
1520MM |
2.2*1.9*1.52 |
5.5KW|380V |
LRL**-N |
Custom-made according to the requirement |
|||||
