High heat resistance customized ceramic steatite ceramic refractory ceramic
- 20000 Piece / Pieces per Month
- Shanghai
- Credit Card
You May Like
-
High temperature resistance insulating ceramic pipe customized steatite ceramic tubes
-
High temperature resistance insulating ceramic tube refractory steatite industrial ceramic
-
high quality best service UV curing lamp holder UV lamp cap steatite UV ceramic lamp base
-
high heat transfer ceramic cap projector lamp steatite ceramic socket
-
high temperature resistance supper insulating wear resistance steatite ceramic cover resistance ceramic
-
high temperature resistance supper insulating wear resistance ceramic quartz tube steatite structural ceramic
Product Details
| Place of Origin | Jiangsu, China | Brand Name | SLMK | |
| Model Number | According to your drawing or samples | Type | Insulating Ceramics | |
| Material | Other, steatite |
Product Description
High heat resistance customized ceramic steatite ceramic refractory ceramic
1. Material: Steatite ceramic
| Performance | |||||
| Item | Index | Unit | Steatite ceramic | 95 Al2O3 | 96 Al2O3 |
| Physical Characteristics | Bulk density | g/cm3 | 2.7 | 3.6 | 3.6 |
| Water absorption | % | 0 | 0 | 0 | |
Mechanical Characteristics | Flexural strength | Mpa | 145 | 320 | 340 |
| Hardness Vickers | Gpa | 5.7 | 12.2 | 13.5 | |
| Elastic modulus | Gpa | 120 | 280 | 320 | |
| Poisson’s ratio | - | 0.21 | 0.22 | 0.23 | |
| Thermal Characteristics | Linear expansion coefficient | 20-5000C 10-6/0C | 7.9 | 7.1 | 7.2 |
| Thermal conductivity | w/(m.k) | 2.5 | 16 | 24 | |
| Specific Heat | *10-3J/(kg*K) | 0.75 | 0.78 | 0.78 | |
| Electrical Characteristics | Dielectric constant(1MHZ) | - | 6.2 | 9 | 9.4 |
| Dielectric loss angle | *10-4 | 18 | 15 | 5 | |
| Dielectric strength | *106V/m | 18 | 12 | 15 | |
2. Advantages:
1). Excellent insulation, security.
2). Excellent high pressure resistance
3). Corrosion resistance
3. Main Applications:
1). Shaft, Plunger
2). High-pressure cleaning machines
3). Sealing structure
4). Auto mobile industry
5). Oil drilling equipment
6). Insulation parts in electrical equipment
7). Ceramic knife
8). Ceramic hair clipper spare parts
4. About us:
Jiangsu Sailamike Precision Ceramic is a worldwide leader in the development and production of advanced insulating ceramics. We provide a wide selection of advanced ceramics including Alumina ceramic, Zirconia ceramic, cordierite, steatite ceramic and mullite, which improves and extends the performance of your product, process, or system. Whether you need high temperature stability, high hardness and wear resistance surfaces, improved stiffness to weight radiations, anti-corrosive barriers or low thermal expansion rates - we can deliver. We can offer significant performance and cost advantages to meet your needs.
Welcome you contact us for more information.
