Mobiel  Scissor Lifts Product Advantages:high working capacity, most spacious platforms for several people to work on,easily moved,high strength steel structures,smoothly lifting up and droping down, easily operated,few faults.
Moving method:4 wheel mible or 2 wheel towable, tyres are optional, it could be pnumatic rubber tyres,solid rubber tires or polyurethane tires.
Power sources: local power available at the working sites(110V,220V,380V,415V) Working heights: ranging from 4m,6m,8m,10m,12m,14m,16m,18m,20m(Please refer to the Products Specification List)
Applications: It is widely used for the equipments installations and maintenance at the following places like construction sites workshops,warehouse,granary,bus/railway stations,hotels,airports,gas station and aerial pipeline.

Model #	Load Capacity	Table Size	Lifting Height	Working Height	Overall Dimensions	Dry Weight
SJY0.3-8	300Kg	1800×1200mm	8M	9.7M	2300×1500×1420mm	1240Kg
SJY0.5-8	500Kg	1800×1200mm	8M	9.7M	2300×1500×1450mm	1400Kg
SJY0.8-8	800Kg	1800×1200mm	8M	9.7M	2300×1500×1540mm	1480Kg
SJY0.3-9	300Kg	1800×1200mm	9M	10.7M	2300×1500×1500mm	1000Kg
SJY0.5-9	500Kg	2000×1200mm	9M	10.7M	2500×1500×1550mm	1300Kg
SJY0.3-10	300Kg	2120×l200mm	10M	11.7M	2600×1500×1550mm	1400Kg
SJY0.5-10	500Kg	2120×l200mm	10M	11.7M	2600×1500×1550mm	1550Kg
