Double Power Hydraulic Scissor Lift Platform
- qingdao
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | hontylift | |
| Model Number | SJY0.5-10 | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Hydraulic | Power | 2.2kw | |
| Rated Loading Capacity | 300-2000kg | Min. Lifting Height | 1.54m | |
| Max. Lifting Height | 10m | Table Size | 1800*1200MM | |
| Overall Dimensions | 2600*1500*1540MM | Weight | 1800kg |
Product Description
Specifications
hydraulic scissor lift platform used diesel and AC 220V as power,when AC is not,you can use diesel workdouble power hydraulic scissor lift platform used diesel and AC 220V as power,when AC is not,you can use diesel work , scissor lift platform used maintenace,aloftwork,etc.which Equipped with emergency value, explosion-proof valves,there is 2-phase power or three-phase power supplied and control for electric control, hand pressure pump are also available for the use of power; have a mobile and flexible, smooth movements, easy to operate and so on. The scissor lift tables are suitble for factories, institutions, shopping and building renovation, installation and other industries.movable hydraulic scissor lift table can be use diesel,gasonline engine,generator as power. and the lifting height from 2 m to 20m,and load capacity form 100kg to 5tons. we can design and manufacture as your request !
Name |
Type. | rises height (M) | Raise weight (Kg) | Platform size (mm) | Dimensions (L*W*H) | Power (KW) | Weight |
hydraulic scissor lift platform | SJY0.3-4 | 4 | 300 | 1500*750 | 1700*920*2000 | 2.2 | 400 |
SJY0.3-6 | 6 | 300 | 1500*750 | 1600*900*1240 | 2.2 | 650 | |
SJY0.3-8 | 8 | 300 | 1750*770 | 1950*1100*1350 | 2.2 | 950 | |
SJY0.5-8 | 8 | 500 | 1830*1000 | 2300*1350*1350 | 2.2 | 1500 | |
SJY0.8-8 | 8 | 800 | 2000*1220 | 2600*1500*2640 | 2.2 | 1700 | |
SJY1.0-8 | 8 | 1000 | 2000*1220 | 2600*1550*2640 | 2.2 | 1800 | |
SJY0.3-10 | 10 | 300 | 2080*1220 | 2450*1600*1550 | 2.2 | 1500 | |
SJY0.5-10 | 10 | 500 | 2080*1220 | 2450*1520*2350 | 2.2 | 1600 | |
SJY1.0-10 | 10 | 1000 | 2220*1220 | 2820*1720*2850 | 3.0 | 2380 | |
SJY0.3-12 | 12 | 300 | 2550*1500 | 3050*1950*1750 | 2.2 | 2580 | |
SJY0.5-12 | 12 | 500 | 2550*1500 | 3000*1950*2650 | 2.2 | 2600 | |
SJY1.0-12 | 12 | 1000 | 1600*1500 | 3200*2105*3090 | 3.0 | 3580 | |
SJY0.3-14 | 14 | 300 | 2600*1600 | 3100*2100*1800 | 2.2 | 3000 | |
SJY0.3-16 | 16 | 300 | 3210*1600 | 3890*2120*3030 | 3.0 | 3900 | |
SJY0.3-18 | 18 | 300 | 3210*1600 | 3890*2120*3250 | 3.0 | 4300 |
