Characteristics of YZYX130-9WK
1. Healthy!Physical squeezing craft maximally keeps the nutrients such as the protein, fatty acids and minerals, etc.
2. High working efficiency! The spiral squeezing structure can achieve high oil output, thus the oil content of the residue cake is low.
3. Long durability! All the parts are made of the most suitable material and treated with refined crafts to ensure the long term runing, such as cemented quenching and tempering to increase the hardness, consequently the durability.
4. Cost-effective! The wearing parts on the machine such as the squeeze loop, squeeze spiral and squeeze bar are designed to be dismountable. When they are out of service period, users only need to replace them and no need to displace the whole machine.
Under the combined effects of several forces, such as the pressure generated as the space in the squeeze chest becoming smaller, the propulsion of the revolving spiral axes, the resistance of the multilateral arc curves on the squeeze loops, the extrusion & friction between the oil plants, oil squeezed from the oil plants comes out from the squeeze bars and the grooves of the squeeze loops. The residue is conveyed to the end of the press chest and discharges in thin strips of oil cake from the space between the cake adjuster and the loop for cake out. Then the whole separation process of oil from oil plants is completed.
| Processing capacity(t/24h) | 8~10 |
| Residue oil of the cake(%) | ≤8.0 |
| Main electromotor power(kw) | 15 |
| Temperature control power(kw) | 3.6 |
| Measurement(mm)(L×W×H) | 1950×742×1500 |
| Weight(kg) | 825 |
Our service:
*Warranty period: 1 year for main parts.
*We offer spare parts all the year round.
*We offer best products solution from professional engineers with more than 30 years experience.
*24 hours online customer service, welcome contact with us freely.
FAQ
1. Delivery time.
---20~30 days after order confirmation. We need time to prepare machine according to exporting standard, wear-in, making wooden box, fumigation and suitable ship arrangement from forwarder.
2. If I don't know how to operate this machine? how can I do?
----Our machine has been tested OK and fully assembled before shipping, customer just needs to make2~4 hours wear-in and then can work.
3. What's wear-in for new machine?
---- use 10 KG oil cake + 1KG sand + 1KG water, mix them, put in oil press, wear in 3~4hs.
1st hour, adjust oil cake thickness as 3mm.
2nd hour, adjust oil cake thickness as 2.5mm.
3rd hour, adjust oil cake thickness as mm.
4. What are cold press and hot press?
----Cold press is pressing dry and raw seeds. Usually need to press 2 times to get maximum oil.
----Hot press is pressing roasted seeds. Usually only press 1 time to get maximum oil. peanuts roast to 125~130 degree with 1~2% moisture. (We produce seeds roaster heated by economical fuel.)
