mobile scissor lift, mobile scissor lift Manufacturers
1.Mobile Scissor lift driving force
· When the AC electricity is available, usually for Indoor use
· No noise and air pollution
· Voltage: 110V, 220V, 380V,
B.Battery Powered / DC powered
· When the AC electricity is not available, usually for Outdoor use
· No noise and air pollution
C. Diesel Powered
· When the electricity is not available, usually for Outdoor use
· Longer use time
2.mobile scissor lift safety protection
mobile scissor lift has various protection measures as follows
- Explosion-proof valves :protect hydraulic pipe ,anti-hydraulic pipe rupture
- Spillover valve :it can prevent high pressure when the machine moves up ,adjust the pressure
- Emergency decline valve :it can go down when you meet an emergency
- Phase lack &phase dislocation protection
video link of mobile scissor lift : /watch?v=x5yKcAaHvW4
Features + Benefits
- Platform controls are equipped with on-board diagnostics
- Auxiliary platform lowering system enables platform descent, even in the event of a power failure
- Zero inside turning radius
- Non-marking tires won't mar the floor surface
- 2.1m. x 0.8m. base provides sturdy performance
| Type | Platform (mm) | Dimension(mm) | Guardrail (mm) | Lifted height (mm) | Load (kg) | Weight (kg) | Power |
| HTCY0.3-4 | 2100*800 | 2200*900*1100 | 1050 | 4 | 300 | 400 | 220v/2.2kw |
| HTCY1.0-4 | 2100*1100 | 2200*1400*1300 | 1050 | 4 | 1000 | 680 | 380v/2.2kw |
| HTCY2.0-4 | 2100*1500 | 2200*1800*1400 | 1050 | 4 | 2000 | 800 | 380v/2.2kw |
| HTCY0.3-6 | 2100*800 | 2200*900*1290 | 1050 | 6 | 300 | 650 | 220v/2.2kw |
| HTCY1.0-6 | 2100*1200 | 2200*1500*1450 | 1050 | 6 | 10000 | 1000 | 380v/3kw |
| HTCY2.0-6 | 2100*1500 | 2200*1800*1600 | 1050 | 6 | 2000 | 1600 | 380v/3kw |
| HTCY0.3-8 | 2100*900 | 2200*1100*1390 | 1050 | 8 | 300 | 720 | 220v/2.2kw |
| HTCY0.5-8 | 2100*1200 | 2200*1500*1450 | 1050 | 8 | 500 | 1500 | 380v/2.2kw |
| HTCY1.0-8 | 2100*1200 | 2200*1500*1530 | 1050 | 8 | 1000 | 1700 | 380v/2.2kw |
| HTCY2.0-8 | 2100*1500 | 2200*1950*1800 | 1050 | 8 | 2000 | 2800 | 380v/3kw |
| over 8 meters | |||||||
| HTCY0.3-10 | 2100*1200 | 2200*1500*1530 | 1050 | 10 | 300 | 1500 | 380v/2.2kw |
| HTCY1.0-10 | 2200*1500 | 2300*1950*1950 | 1050 | 10 | 1000 | 2500 | 380v/3.0kw |
| HTCY2.0-10 | 2600*1500 | 2750*1950*1950 | 1050 | 10 | 2000 | 3000 | 380v/3.0kw |
| HTCY0.3-12 | 2530*1500 | 2750*1950*1740 | 1050 | 12 | 300 | 2580 | 380v/2.2kw |
| HTCY1.0-12 | 2700*1600 | 2900*1950*1950 | 1050 | 12 | 1000 | 3200 | 380v/3.0kw |
| HTCY2.0-12 | 2700*1600 | 2900*1950*1950 | 1050 | 12 | 2000 | 3500 | 380v/4.0kw |
| HTCY0.3-14 | 2750*1500 | 2900*1950*1970 | 1050 | 14 | 300 | 3000 | 380v/3.0kw |
| HTCY1.0-14 | 3100*1600 | 3300*1950*2200 | 1050 | 14 | 1000 | 3000 | 380v/4.0kw |
| HTCY0.3-16 | 3200*1600 | 3400*1980*2030 | 1050 | 16 | 300 | 3600 | 380v/3.0kw |
| HTCY0.3-18 | 3500*1800 | 3800*2000*2200 | 1050 | 18 | 300 | 4700 | 380v/4.0kw |
1. The equipment is mainly used to lift workers to higher places for maintenance, cleaning or installation.
2. An ideal equipment of safe operation
3. It is characterized by great loading capacity.
4. Steady ascending and descending
5. Mobile convenient, easy to work.
6. Local voltage can be customerized (110V, 220V, 380V)
Factory name |
jinan hontylift machinary co.,ltd |
Factory address |
No .8 Huixin Road Jiyang county Jinan North Development Zone Shandong China |
Business character |
Integration of industry & trade |
workshops |
6 |
employees |
86~115 |
factory area |
199800m³ |
Manufacturing experience |
7 years since 2009 |
Exporting experience |
5 years since 2011. |
websites |
/ http://honty.en.china.cn/ / |
Service |
06:00am ~23:00pm pre-sale service , 06:00am ~23:00pm after-sale service |
Price advantage |
Factory directly sell |
Visit factory |
Anytime clients will be welcomed if visit factory, we can pick clients at airport or train station |
FAQ
1. Factory or trading company?
We are factory : jinan hontylift machinary co.,ltd
2. Payment terms ?
30%TT before production, 70%TT before shipment ,
T/T, L/C, Western Union, PayPal, other kinds, pls contact with us.
3. Where have you been exported?
Saudi Arabia, Egypt , Colombia, ,Malaysia, Taiwan, Turkey, Senegal , Russia,Thailand, ect
4. Warranty &after-sales service?
Since you got the goods , one year free from man made faults; the installation , maintenance , and operation guide books and video will be provided. On-line service will be provided.
5. Pre-sales service 06:00am~23:00pm After-sales service 06:00am~23:00pm on whatsapp 008618763961675
Skype
6. Delivery time
Within 7- 15 working days after we receive the order.
7. MOQ
the MOQ is 1 set
8. Custom-made or not ?
yes , produce as your requirement , also OEM .
contact us
Company : jinan hontylift manchinary co.,ltd
Address : No .8 Huixin Road Jiyang county Jinan North Development Zone Shandong China
Website :
Contact :Tiny
E-mail : tiny-sale#(change # into @)
whatsapp :008618763961675
Mobile phone:008618763961675
Wechat : tiny19931205
qq:2860351785
skype:
Feel free to contact me if you have any question , I will reply ASAP
